Talleres Radioeléctricos Querol, S.L.
Self contained Emergency Informative SIGN
SERIE MIZAR SI
Technical Characteristics:
Supply 230V~ 50/60Hz.
-
Maintained.
-
Stand by and re-start via Telemando( TM).
-
-
Green Led indicating, the Battery re-charging.
Illumination via High luminosity white led.
-
-
Stabilized current of Led (constant current control).
Visibility 40 mts. (As per NORM UNE-EN 1838).
-
-
Autonomy 3 hours.
Battery Ni-Cd 6V – 0,8Ah.
-
-
Luminous Flux: 2 lm.
Cos ϕ = 0,8.
-
Protection Grade IP40.
-
Connection via ∅6 mm cable.
-
Overload & end of battery discharge protection.
-
Class II Luminary.
-
Metacrilate Diffuser of 8 mm width.
-
-
Frontal, lateral mounting & suspended via cable
-
Pictograms & mounting accessories included.
.
F
IP40
Advertisement
Table of Contents
Related Manuals for TRQ MIZAR SI Series
Summary of Contents for TRQ MIZAR SI Series
- Page 1 Talleres Radioeléctricos Querol, S.L. IP40 Self contained Emergency Informative SIGN SERIE MIZAR SI Technical Characteristics: Supply 230V~ 50/60Hz. Maintained. Stand by and re-start via Telemando( TM). Green Led indicating, the Battery re-charging. Illumination via High luminosity white led. Stabilized current of Led (constant current control). Visibility 40 mts.
- Page 2 Technical Drawing: Norms Applied: CE marked as per 73/23 CEE y 89/336 CEE. UNE-EN 60598-2-22 UNE-EN 60598-1 UNE-EN 1838 Installation: Place the 2 polycarbonate pictograms (one per side) and fix them to the metacrilate diffuser by the means of 4 plastic screws included.(see the fig) Install the luminary as required (wall, or ceiling) as indicated in the fig.
- Page 3 Models Available: Model Dim. Pictogram Visibility Type MIZAR SI 1 200x200 EXTINGUSHER 40 mts. Maintained MIZAR SI 2 200x200 ALARM BUTTON 40 mts. Maintained MIZAR SI 3 200x200 FIRE PIPE 40 mts. Maintained PICTOGRAMS: MIZAR SI1 MIZAR SI 2 MIZAR SI 3...
- Page 4 Installation : Mounting of Pictogram: Cable connections: Wall mounting ( lateral(): Wall mounting ( frontal): Ceiling mounting (with chaine): Ceiling mounting (direct): Change of battery:...
- Page 5 Connection diagram:...
