BB1000
OWNER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for bioBidet BB1000

Summary of Contents for bioBidet BB1000

  • Page 1 BB1000 OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PRODUCT INFORMATION Important Safeguards & Cautions....4 Cautions Before Installation........6 Main Unit & Parts............8 PRODUCT INSTALLATION Installation..............9 How To Detach the Unit........12 Testing & Seat Bumpers........13 PRODUCT OPERATION Operation..............14 Maintenance..............25 Troubleshooting Guide........28 Specifications............30 WARRANTY Warranty..............32...

  • Page 3: Important Safeguards & Cautions

    IMPORTANT SAFEGUARDS & CAUTIONS READ ALL OPERATING INSTRUCTIONS BEFORE INSTALLATION • This product must be connected to a standard voltage power source. Do not connect power cord if the cord is damaged or broken. • This product should be installed according to this manual. Do not plug the unit into a loose electric outlet.

  • Page 4: Cautions Before Installation

    IMPORTANT SAFEGUARDS & CAUTIONS (CONT.) CAUTIONS BEFORE INSTALLATION WIRING REQUIREMENT This product MUST be plugged into a regular voltage Grounded GFCI outlet (North America 120V ac, 60Hz/ Europe 220-240V ~, 50/60Hz). The rated power consumption is 660W/600-700W. In locations where only a standard two-prong outlet is available, it is the responsibility of the user to install a grounded three-prong outlet.
  • Page 5 CAUTIONS BEFORE INSTALLATION (CONT.) OPTIONAL GROUNDING INSTRUCTIONS DANGER IMPROPER USE OF GROUNDING CAN RESULT IN A RISK OF ELECTRIC SHOCK. ELECTRIC WIRING HAS TO BE DONE IN ACCORDANCE WITH ALL LOCAL CODES, OR IN THE ABSENCE OF LOCAL CODES, WITH THE NATIONAL ELECTRICAL CODES.

  • Page 6: Main Unit & Parts

    MAIN UNIT & PARTS INSTALLATION CAUTION BEFORE INSTALLATION • Do not plug in before installation • If you need an electric power system or extension, please consult a qualified electrician. • Please contact out service center at 847.458.2334 when you want to reinstall the bidet product (move or replacement).

  • Page 7: Installation

    INSTALLATION (CONT.) 3. Connect the T-valve. 4. Connect the water 7. Assembly. 8. Bidet Hose Assembly. supply hose to the assembled T-valve. Water supply hose 1/2"conversion nut • Remove existing supply hose • Remove the existing supply hose • Slide this product onto the catch •...

  • Page 8: How To Detach The Unit

    INSTALLATION (CONT.) HOW TO DETACH THE UNIT 9. Deodorizer Installation DO NOT TURN UNIT UPSIDE DOWN. • Disconnect the power plug. • Close water supply shut-off valve. • Drain water from bidet seat using drainage as illustrated. • Remove bidet seat from the toilet as illustrated.

  • Page 9: Testing & Seat Bumpers

    TESTING & SEAT BUMPERS OPERATION Adjust the water pressure and warm air dryer temperature. Adjust the oscillation function and nozzle position (5 levels). Adjust the water and seat temperature (4 levels). • Plug the power cord into • After installing your bidet Power Saving mode button.

  • Page 10: Operation

    OPERATION (CONT.) OPERATION TURBO WASH • Press “Turbo Wash,” the nozzle spray is more or focused to produce the Sit Down On the Seat effect of strong wash, to help stimulate bowel movement. • When you sit down on the seat, the ORANGE LED lamp on the control •...
  • Page 11 OPERATION (CONT.) TURBO WASH WARM WATER TEMPERATURE AND SEAT TEMPERATURE ADJUSTMENT • Press “Turbo Wash” continuously for 3 to 5 seconds. Automatically, the water nozzle comes out and sprays a warm stream of water to the • The temperature of water and seat are adjustable to the desired level by posterior center of the rectum.
  • Page 12 OPERATION (CONT.) Auto-Setting of Oscillation Feature AUTO SETTING OF MASSAGE FEATURE You can set this function to automatically oscillate whenever the seat is You can set this function to automatically pulsate whenever the seat is occupied and the Posterior or Feminine washes are in operation. occupied and the Posterior or Feminine washes are in operation.

  • Page 13: Maintenance

    Carbon & Iodine water filters. The purchase or use of any other water filter is not the responsibility of Bio Bidet Innovation LLC. As such, any use of non Carbon or Iodine water filters is prohibited and will void the warranty for those Bio Bidet products.
  • Page 14 MAINTENANCE CONT. WATER DRAINING CLEANING THE STRAINER If you do not intend to use this product THIS PRODUCT WILL NOT OPERATE for 14 days or longer, drain the water PROPERLY IF THE STRAINER IS from the product’s warm water tank CLOGGED.

  • Page 15: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM POSSIBLE POSSIBLE SOLUTION PROBLEM POSSIBLE POSSIBLE SOLUTION CAUSE CAUSE • The water tank • Wait about one minute. • The water • Set the water pressure The washing water does is not filled. Press the desired washing washing pressure level is to be “HIGH.”...

  • Page 16: Specifications

    SPECIFICATIONS SPECIFICATION BB-800 SPECIFICATION BB-800 Power Rating Australia or Europe: 240-240V~, 50/60Hz, Turbo Function 600-700W Inlet water temperature 3°C~35°C (37.4°F ~ 95°F) America or Canada: 120Vac, 60Hz, 660W Ambient Temperature 3°C ~ 40°C (37.4°F ~ 104°F) Water Type Direct Inlet flow type Dimension ELONGATED ROUND (Control)

  • Page 17: Warranty

    To obtain warranty repair service under this warranty, you must take the • 75% Coverage of all parts for the entire product for the second year from product or deliver it prepaid to a Bio Bidet Innovation LLC service facility the original date of purchase together with a letter stating the problem, or contact a Bio Bidet Innovation •...
  • Page 18 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off BIO BIDET INNOVATION LLC and on, the use is encouraged to try to correct the interference by one more...
  • Page 19 Thank You Technical Support/Customer Service 7900 S Route 31 Crystal Lake, IL 60014 T: 847.458.2334 U.S. TOLL FREE: 877.339.5214 support@biobidet.com www.biobidet.com...
