Installation Guide Lighting Fixture
MUSEUM platform / Adjustable downlight
MMP-130A/40B/Z1/2
Installation Details Installation Diagram
Wiring connection
Please connect according to
the description of a power supply.
Optional parts installation
2
Turn around the body.
1
2 Pull out the body from the hood.
Turn around the option holder,
3
and put out .
4
Put a filter in hood.
5 Turn around the option holder,
and put in.
3
Please attention that
the sharpener lens is counted
UP to
two pieces of filter lenses.
2FILTERS
Donʼt put in the filters than
f
the rule number of pieces.
Causes of falling and damage.
Tilting angle setting
Please loose a screw by the
1
hexagonal wrench,and unrock.
Please regulate a point of view
2
to a scale.
Please use an attached hexagon
wrench by all means.
Caution
Wiring diagram
PE N L
DC1200mA
36.8V
L N PE + -
Driver
f
Body
OPTION
UP to 2FILTERS
HOLDER
1
Hood
OPTION
HOLDER
5
Sharpner
FILTER
lends
4
Inner HOOD
2
hexagonal wrench
1
Installation Details
Installation to ceiling
1 Install the safety wire to the
mounting frame.
+RED
Install the fixture to the mounting
2
frame.
-BLACK
LED
Make sure to install the safety wire
h
to the mounting frame securely.
Do not touch inner side of the body
with bare hands. Use clean soft
cloth to clean up and maintain
inner side of the body.
Make sure the fixture will not touch
any objects in ceiling.
Sharpner
lends
R
Installation Diagram
Safety wire
1
2 Ceiling
Mounting frame
Body
As you support edge of a main part,
please push it
.
※An inside glass filter is
not touched by hand .
