Wire or RCA Connector
Function
Zone 1 subwoofer out
Zone 2 line out (left)
Zone 2 line out (right)
Zone 2 subwoofer out
Auxiliary in left
Auxiliary in right
Zone 3 line out (left)
Zone 3 line out (right)
Zone 3 subwoofer out
6
Bare Wire Color
or RCA Label
Notes
Name
ZONE 1 SUB
Each subwoofer cable provides a single mono output to a
OUT
powered subwoofer or subwoofer amplifier.
Provides output to an external amplifier, and is associated
ZONE 2
with the volume control for zone 2.
ZONE 2 SUB
Each subwoofer cable provides a single mono output to a
OUT
powered subwoofer or subwoofer amplifier.
Provides an RCA stereo line input for audio sources, such
AUX IN
as a CD or MP3 player.
Provides output to an external amplifier, and is associated
with the volume control for zone 3.
ZONE 3
Each subwoofer cable provides a single mono output to a
powered subwoofer or subwoofer amplifier.
Apollo MS-RA670 Installation Instructions
