  • Page 1 IMMFP12 Multi-Function Processor Module Process Control and Automation Solutions from Elsag Bailey Group...
  • Page 2 The information contained in this document is subject to change without notice. Elsag Bailey, its affiliates, employees, and agents, and the authors and contributors to this publication specif- ically disclaim all liabilities and warranties, express and implied (including warranties of merchantability and...
  • Page 3 Preface The IMMFP12 Multi-Function Processor Module is a powerful stand-alone controller for use in complex control applications. It has the processing speeds and storage capabilities necessary for advanced control applications. The IMMFP12 module is a user-configurable device that receives process input and out- put through a variety of analog and digital I/O modules.
  • Page 4 ® List of Effective Pages Total number of pages in this instruction is 72, consisting of the following: Page No. Change Date Preface Original List of Effective Pages Original iii through viii Original 1-1 through 1-6 Original 2-1 through 2-4 Original 3-1 through 3-10 Original...

  • Page 5: Table Of Contents

    Table of Contents Page SECTION 1 - INTRODUCTION ....................1-1 OVERVIEW ........................1-1 INTENDED USER ......................1-1 HARDWARE DESCRIPTION ..................1-1 Faceplate .......................1-2 Circuit Board ......................1-3 HARDWARE APPLICATION ...................1-3 FEATURES........................1-3 INSTRUCTION CONTENT .....................1-3 HOW TO USE THIS MANUAL ..................1-4 REFERENCE DOCUMENTS..................1-4 NOMENCLATURE ......................1-4 DOCUMENT CONVENTIONS ..................1-5 GLOSSARY OF TERMS AND ABBREVIATIONS .............1-5 SPECIFICATIONS ......................1-6 SECTION 2 - DESCRIPTION AND OPERATION................2-1...
  • Page 6 ® Table of Contents (continued) Page SECTION 4 - OPERATING PROCEDURES (continued) Red/Green Status LED ..................4-2 STOP/RESET SWITCH....................4-3 MODES OF OPERATION ....................4-4 Configure Mode ..................... 4-4 Execute Mode ......................4-4 Error Mode ......................4-4 SECTION 5 - TROUBLESHOOTING...................5-1 INTRODUCTION ......................
  • Page 7 Table of Contents (continued) Page APPENDIX C - NTMP01 TERMINATION UNIT CONFIGURATION........... C-1 INTRODUCTION......................C-1 APPENDIX D - NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION....... D-1 INTRODUCTION......................D-1 List of Figures Title Page 1-1. Example IMMFP12 Module Applications ..............1-2 2-1. IMMFP12 Module Functional Block Diagram ............2-1 3-1.
  • Page 8 ® List of Tables Title Page 1-1. Reference Documents .................... 1-4 1-2. Nomenclature ......................1-5 1-3. Glossary of Terms and Abbreviations ..............1-5 1-4. Specifications ......................1-6 3-1. IMMFP12 Dipswitch SW3 Settings ................. 3-3 3-2. Example IMMFP12 Module Address Settings ............3-4 3-3.
  • Page 9 Safety Summary GENERAL Equipment Environment WARNINGS All components, whether in transportation, operation or storage, must be in a noncorrosive environment. Electrical Shock Hazard During Maintenance Disconnect power or take precautions to insure that contact with energized parts is avoided when servicing. Special Handling This module uses electrostatic sensitive devices (ESD).
  • Page 10 ® Trademarks and Registrations Registrations and trademarks used in this document include: ® INFI 90 Registered trademark of Elsag Bailey Process Automation ® INFI-NET Registered trademark of Elsag Bailey Process Automation ® Network 90 Registered trademark of Elsag Bailey Process Automation...

  • Page 11: Section 1 - Introduction

    SECTION 1 - INTRODUCTION OVERVIEW The IMMFP12 Multi-Function Processor Module (MFP) is one of ® the workhorses of the INFI 90 OPEN control module line. It is a multiple loop analog, sequential, batch and advanced con- troller that provides powerful solutions to process control problems.

  • Page 12: Faceplate

    INTRODUCTION ® ® IN F I-N ET O R P L A N T L O O P P RO C ES S C O N T RO L N IS N P M U N IT IN T ER FAC E C O N TRO LWAY S EC O N DA RY P R IM ARY...

  • Page 13: Circuit Board

    (RAM), read only memory (ROM), a microproces- sor running at 16 megahertz, direct memory access (DMA) cir- cuits, Elsag Bailey custom bus circuits and various support circuitry. The board attaches to the faceplate with two screws. The module assembly occupies one slot in a module mounting unit.

  • Page 14: How To Use This Manual

    INTRODUCTION ® Repair/Replacement This section describes how to maintain and replace the module. Procedures Support Services A list of the replacement parts and an explanation of the war- ranty policy are contained in this section. Appendices These appendices provide quick reference information for the hardware configuration of the IMMFP12 module and associ- ated termination units and modules and step by step instruc- tions for performing on-line configuration.

  • Page 15: Document Conventions

    The ? in a nomenclature or a part number indicates a variable for that position (e.g., IMMFP1?) GLOSSARY OF TERMS AND ABBREVIATIONS Table lists the definitions of terms and abbreviations used in this instruction that are unique to Elsag Bailey. Table 1-3. Glossary of Terms and Abbreviations Term Description Configuration The act of setting up equipment to accomplish specific functions or a list of parame- ters associated with such a setup.

  • Page 16: Specifications

    INTRODUCTION ® Table 1-3. Glossary of Terms and Abbreviations (continued) Term Description Process control unit. A node on the plantwide communication network containing control and I/O modules. Analog control station. Termination Module Provides input/output connection between plant equipment and the INFI 90 OPEN/ Network 90 modules.

  • Page 17: Section 2 - Description And Operation

    SECTION 2 - DESCRIPTION AND OPERATION INTRODUCTION The IMMFP12 Multi-Function Processor Module functions like a series of functional blocks working together. To explain how the MFP module works, this section shows MFP module func- tionality as a block diagram (refer to Figure 2-1) and then explains each block in the following text.

  • Page 18: Clock And Timer

    I/O data between control and I/O modules. It supports up to 64 low power I/O modules. The bus uses a protocol designed by Elsag Bailey to ensure data integ- rity. The bus bandwidth is 500 kilobytes per second, however actual throughput is about 100 kilobytes per second.

  • Page 19: Serial Channels

    32 connections. The Controlway interface is provided by a custom Elsag Bailey integrated cir- cuit that links the MFP module to the Controlway. It has full DMA capabilities (allowing for quicker operation), and two redundant, independent communication channels.

  • Page 20: Redundancy Link

    DESCRIPTION AND OPERATION ® There are two separate communication paths on the module mounting unit backplane circuit allotted for Controlway com- munications. Data is transmitted over both channels simulta- neously and received in separate receivers where it is checked for integrity. In this way, the Controlway minimizes the chances that a failure on a circuit board, or the backplane will cause loss of module communication.

  • Page 21: Section 3 - Installation

    SPECIAL HANDLING Observe these steps when handling electronic circuitry: NOTE: Always use Elsag Bailey field static kit (part number 1948385?1 - consisting of two wrist straps, ground cord assembly, alligator clip, and static dissipating work surface) when working with the modules.

  • Page 22: Unpacking And Inspection

    UNPACKING AND INSPECTION 1. Examine the hardware immediately for shipping damage. 2. Notify the nearest Elsag Bailey sales office of any such damage. 3. File a claim for any damage with the transportation com- pany that handled the shipment.

  • Page 23: Dipswitch Sw3 Settings

    INSTALLATION Dipswitch SW3 Settings Dipswitch SW3 sets the bus mode and address of the MFP module. The MFP module can have an address from zero -3 0 V D C SY S TE M (D E FAU LT) R E SE RV ED C O N TRO LW AY R E SE RV ED S W 3...

  • Page 24: Dipswitch Sw4 Settings

    INSTALLATION ® Table 3-1. IMMFP12 Dipswitch SW3 Settings User Pole Setting Function Setting Controlway (1 Mbaud) mode. Module bus (83.3 kbaud) mode. 4 - 8 2 - 31 Controlway or module bus address. NOTE: 0 = CLOSED or ON, 1 = OPEN or OFF; shaded areas designate mandatory pole settings. 1.

  • Page 25: Special Operations

    INSTALLATION Table 3-3. IMMFP12 Dipswitch SW4 Normal Operation Settings (continued) Pole Setting Function User Setting Normal operation. The compact configuration function moves configured function blocks to the top of the NVRAM memory while moving free space to the bottom. This condenses the configured function blocks while providing the largest possible area of contiguous unconfigured function blocks to the user.

  • Page 26: Jumpers J1 Through J5

    INSTALLATION ® Table 3-4. IMMFP12 Dipswitch SW4 Special Operation Settings (continued) Dipswitch Position Special Description Operation 2 3 4 5 6 7 8 1 0 0 0 0 1 0 1 Permit segment modification (allows change to segment scheme configured with function code 82, specification S1). 1 0 0 0 0 1 1 0 Enable time stamping.

  • Page 27: Preparing The Module Mounting Unit

    NOTE: Two unlabeled header pin holes are located at the front of the board. These are for Elsag Bailey development personnel usage only. They are used to disable the machine fault timer circuit. If this function is disabled (header pins connected) and a problem devel- ops in the MFP module, the module will not halt.

  • Page 28: Controlway Cable

    INSTALLATION ® Controlway Cable Install the Controlway or module bus cable in INFI 90 OPEN module mounting units as follows: 1. Attach one end of the Controlway or module bus cable (twisted 3-wire) to the bottom three tabs on the lower left of the module mounting unit backplane (facing from behind).

  • Page 29: Nimp01 Or Nimp02 Termination Module Installation

    INSTALLATION T 00 06 3 A Figure 3-2. Controlway Cable Installation NIMP01 or NIMP02 Termination Module Installation 1. Configure the jumpers on the termination module. Refer to Appendix D for quick reference or to the appropriate instruc- tion for detailed information on jumper settings and applica- tions.
  • Page 30 INSTALLATION ® Before installing the MFP module: 1. Check all module dipswitch and jumper settings (normal and special operation) 2. Insure that respective module cables are attached to their proper slot in the module mounting unit backplane. To avoid potential module damage, evaluate your system for compatibility prior to module installation.

  • Page 31: Section 4 - Operating Procedures

    SECTION 4 - OPERATING PROCEDURES INTRODUCTION This section explains what happens to the IMMFP12 Multi-Function Processor (MFP) Module during start-up, the LED indicators and what they mean, how to stop or reset the module, and the three modes of operation. STARTUP When power is applied to the MFP module, the module does an internal hardware check, checks its configuration and builds...

  • Page 32: Front Panel Leds One Through Eight

    OPERATING PROCEDURES ® IM M FP 1 2 R E D /G R E E N S TATU S L E D L ED s 1-8 S TO P /R E S ET S W IT C H T 01 6 05 A Figure 4-1.

  • Page 33: Stop/Reset Switch

    OPERATING PROCEDURES Flashing Green The MFP module is in execute mode but there is an NVRAM checksum error, or the MFP module is in configure or error mode. The MFP module diagnostics have detected a hardware failure, Solid Red configuration problem, etc. and have stopped the module. Additionally, LEDs one through eight will illuminate in a cer- tain combination to display the error code.

  • Page 34: Modes Of Operation

    OPERATING PROCEDURES ® Recover from a module time-out or operator-initiated stop. • NOTE: Pressing and holding the stop/reset switch provides no addi- tional functionality over pressing and releasing the switch. To stop the module, press and release the stop/reset switch. To reset the module, press the stop/reset switch a second time.

  • Page 35: Section 5 - Troubleshooting

    NVRAM memory opened Initialize the NVRAM memory. If the for write operation error recurs, replace the MFP module. If error recurs call Elsag Bailey field service. 0 0 0 0 1 1 0 1 Redundancy link Check the cable connection between communication error primary and secondary MFP modules.
  • Page 36 Replace the primary and/or secondary during failover attempt module to determine the faulty module. 0 0 1 1 0 0 0 1 Memory or CPU fault Replace the MFP module. If error recurs, call Elsag Bailey field service. INTRODUCTION 5 - 2 WBPEEUI230019A0...

  • Page 37: Other Immfp12 Module Led Conditions

    0 0 1 1 0 1 1 1 Any trap instruction 0 0 1 1 1 0 0 0 Board level hardware Contact Elsag Bailey field service. error 0 0 1 1 1 1 1 1 Normal stop None.

  • Page 38: Immfp12 Troubleshooting Flowchart (Serial Port)

    TROUBLESHOOTING ® S TA RT R S -23 2 -C L IN E E R R O R S O N D O N E M F P LE D S (C O D E 1 5)? Y E S R E F E R TO T M P /IM P +2 4 V D C O P E N O N...

  • Page 39: Card Edge Connectors

    TROUBLESHOOTING S TA RT S TAT U S S TAT U S L ED S TAT U S L ED S TAT U S L ED L E D O F F ? O R AN G E? G R EE N ? R E D ? Y E S Y E S...

  • Page 40: Diagnostics

    TROUBLESHOOTING ® Table 5-4. IMMFP12 Connector P2 Pin Assignments Signal Signal Data Bit 1 Data Bit 0 Data Bit 3 Data Bit 2 Data Bit 5 Data Bit 4 Data Bit 7 Data Bit 6 Bus Clock Synchronization Reserved Reserved NOTE: All data bits are true low.

  • Page 41: Dipswitch Selection

    TROUBLESHOOTING The typical procedure is to select a diagnostic test to execute, set the module dipswitches accordingly, reset the module, and observe the results on LEDs one through eight. The selected test executes repeatedly until the MFP module is reset and another test is selected.

  • Page 42: Diagnostic Dipswitch Settings

    TROUBLESHOOTING ® D IP S W ITC H S W 3 O F F M O D U L E A D D R E S S B U S M O D E (O F F = M O D U L E B U S , O N = C O N T R O LW AY ) U N U S E D D IA G N O S T IC M O D E (O FF = E N A B L E D, O N = D IS A B L E D ) D IP S W ITC H...

  • Page 43: Led Display

    TROUBLESHOOTING Table 5-8. Diagnostic Tests (continued) Test Name Test ID Description I/O Expander Bus Stall Sets a latch enabling a level 7 interrupt to occur. Module Bus/Controlway Sends series of bytes to Controlway verifying timing and transfer status. Timer IRQ Initializes DUART timer for 1-msec interrupts and then waits for it to time-out.

  • Page 44: Module Status Summary

    TROUBLESHOOTING ® LE D 1 LS B LE D 2 PA S S C O U N T LE D 3 T E S T N U M B E R M S B LE D 4 LE D 5 LS B LE D 6 FA ILU R E C O U N T...

  • Page 45: Nomenclature

    TROUBLESHOOTING Table 5-9. IMMFP12 Module Status Report Byte MODE MODULE TYPE Bytes 3-5 combine to define other errors. Extended module type = 24 8 - 13 Unused Nomenclature (decimal digit) Firmware revision level (ASCII letter) Firmware revision level (ASCII digit) NOTE: 1.
  • Page 46 TROUBLESHOOTING ® Table 5-10. Field Descriptions of the IMMFP12 Module Status Report (continued) Field Value Description Bytes 3 through 5 (continued) Analog input reference error: 1 V reference 5 V reference <X> <Y> Missing I/O module: XY = block no. <X>...

  • Page 47: Section 6 - Maintenance

    The reliability of any stand-alone product or control system is affected by the maintenance of the equipment. Elsag Bailey recommends that all equipment users practice a preventive maintenance program that will keep the equipment operating at an optimum level.

  • Page 48: Equipment And Tools Required

    MAINTENANCE ® Table 6-1. Preventive Maintenance Schedule Task Frequency Check cabinet air filters. Clean or replace them as necessary. Check the air filter more fre- 3 months quently in excessively dirty environments. Check cabinet and MFP module for dust. Clean as necessary using an antistatic vacuum. Check all MFP module signal, power and ground connections within the cabinet.

  • Page 49: General Cleaning And Washing

    MAINTENANCE GENERAL CLEANING AND WASHING If the printed circuit board needs minor cleaning, remove dust and residue from the printed circuit board surface using clean, dry, filtered compressed air or an antistatic field service vac- uum cleaner. Another method of washing the printed circuit board is: 1.
  • Page 50 MAINTENANCE ® tightened. If the connection is tight, the tightening action will verify that it is secure. There must not be any motion done to loosen the connection. NOTE: Power to the cabinet must be off while performing this pre- ventive maintenance task.

  • Page 51: Section 7 - Repair/Replacement Procedures

    SECTION 7 - REPAIR/REPLACEMENT PROCEDURES INTRODUCTION Repair procedures are limited to module replacement. If the IMMFP12 Multi-Function Processor Module fails, remove and replace it with another. Verify that firmware revision levels match and that the replacement module switch and jumper settings are the same as those of the failed module.

  • Page 52: Section 8 - Support Services

    SECTION 8 - SUPPORT SERVICES INTRODUCTION Bailey Controls Company is ready to help in the use and repair of its products. Contact the nearest sales office to make requests for sales, applications, installation, repair, overhaul and maintenance contract services. REPLACEMENT PARTS AND ORDERING INFORMATION When making repairs, order replacement parts from a Bailey Controls Company sales office.

  • Page 53: Appendix A - Immfp12 Quick Reference Material

    APPENDIX A - IMMFP12 QUICK REFERENCE MATERIAL INTRODUCTION This appendix provides quick reference information to aid in the hardware configuration of the IMMFP12 Multi-Function Processor Module. Table show the settings for dipswitches SW3 and SW4. Table shows the jumper set- tings for jumper J5.

  • Page 54: Immfp12 Module Error Codes

    IMMFP12 QUICK REFERENCE MATERIAL ® Table A-2. IMMFP12 Dipswitch SW4 Settings (continued) Pole Setting Function Primary MFP module. Redundant MFP module. NOTES: 0 = CLOSED or ON, 1 = OPEN or OFF. 1. Disabling the checksum routine is sometimes done by development personnel and should never be done for normal operation.
  • Page 55 IMMFP12 QUICK REFERENCE MATERIAL Table A-4. IMMFP12 Module Error Codes (continued) Code Condition 8 7 6 5 4 3 2 1 0 0 0 1 0 0 1 0 Primary and secondary module addresses are different 0 0 0 1 0 0 1 1 ROM memory checksum error 0 0 0 1 0 1 0 0 MFP set for INFI-NET, when actu-...

  • Page 56: Other Immfp12 Module Led Conditions

    IMMFP12 QUICK REFERENCE MATERIAL ® Table A-5. Other IMMFP12 Module LED Conditions Condition Problem Status No power, improper module seating, or defective module. Module not properly seated or module defective. GREEN None - normal condition. No power, improper module seating, or defective module.

  • Page 57: Appendix B - On-Line Configuration

    This appendix provides a step by step procedure for performing on-line configuration. Use the configuration and tuning mod- ule, configuration tuning terminal, operator interface station console, management command system console, or engineer- ing workstation with appropriate Elsag Bailey configuration software to accomplish on-line configuration. INTRODUCTION WBPEEUI230019A0...
  • Page 58 PCU status display selected from the system status display. With an engineering work station using the Elsag Bailey CAD/TEXT software package, select the problem report option. Please note that this option does not continuously poll for module status.

  • Page 59: Backup Cycle

    ON-LINE CONFIGURATION Backup Cycle The step numbers in this cycle correspond to the status of Fig- ure B-1. Table B-2. Backup Cycle Primary Backup Procedure 1. Place the backup MFP module into execute mode. This saves a copy of the 00xx0x0x 10xx0x0x primary modules current configuration and enables it to be easily restored if...

  • Page 60: Primary Cycle

    ON-LINE CONFIGURATION ® Table B-2. Backup Cycle (continued) Primary Backup Procedure 5. When the checkpoint data for the old configuration is received from the pri- 01xx0x0x 10xx1x0x mary MFP module, the reconfigured backup MFP module can assume the role of the primary MFP module if a failure is detected in the old configuration (refer to Step 9).

  • Page 61: Backup Mfp Module Operating Cycle

    ON-LINE CONFIGURATION B AC K U P B AC K U P E X T E R R IN IT IA L IZ E B U S C L K C F G E E R O M C F G E X T R E S E T E X T...

  • Page 62: Primary Mfp Module Operating Cycle

    ON-LINE CONFIGURATION ® Table B-3. Primary Cycle (continued) Primary Backup Procedure 4. Resetting the primary MFP module (n+1), currently acting as the hot backup, 00xx0x0x 00xx1x0x directs it to get a copy of the new configuration (Step 9 of the backup cycle). 5.

  • Page 63: Appendix C - Ntmp01 Termination Unit Configuration

    APPENDIX C - NTMP01 TERMINATION UNIT CONFIGURATION INTRODUCTION The IMMFP12 Multi-Function Processor Module can use the NTMP01 termination unit for termination. Jumpers on the NTMP01 unit configure the two RS-232-C ports for data termi- nal equipment (DTE) or data communication equipment (DCE). One of the RS-232-C ports can be configured as an RS-485 port.

  • Page 64: Dce Jumper Configuration For Ntmp01 Termination Unit

    NTMP01 TERMINATION UNIT CONFIGURATION ® J1 AN D J2 R X D D B 2 5 -3 T XD -A R X D -A T XD D B 2 5 -2 RT S -A RT S D B 2 5 -4 C T S D B 2 5 -5 C T S-A...

  • Page 65: Ntmp01 Jumpers J3 Through J10 Configuration

    NTMP01 TERMINATION UNIT CONFIGURATION J1 AN D J2 R X D D B 25-3 T XD -A R X D -A T XD D B 25-2 RTS-A D B 25-4 C T S D B 25-5 C T S-A T 01 6 95 A Figure C-4.

  • Page 66: Ntmp01 Jumpers J14 Through J17 Configuration

    NTMP01 TERMINATION UNIT CONFIGURATION ® D IG IN 1 (+ ) D IG IN 1 (+ ) C T SB (+) C T SB (+) D IG IN 1 (–) D IG IN 1 (– ) C T SB (–) C T SB (–) H A N D SH A K E D IG ITA L I/O...

  • Page 67: Ntmp01 Cable Connections For Redundant Mfp Modules

    NTMP01 TERMINATION UNIT CONFIGURATION TO N TC S 0 4 (C A B L E R E Q U IR E D O N LY IF S TATIO N S A R E U SE D ) N K TU 0 1 N K SE 0 1 N K SE 0 1 N K TU 1 1...

  • Page 68: Appendix D - Nimp01/Nimp02 Termination Module Configuration

    P7 is used instead of P5. NOTES: RS-232-C port connections on the IMP module are through DB-9 connectors. Use Elsag Bailey cable NKMR02 to connect a standard piece of equipment (computer or printer with a DB-25 con- nector) to the IMP module.

  • Page 69: Dte Jumper Configuration For Nimp01 Termination Module

    NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION ® J 1 A N D J2 R X D D B 9-2 T X D -A R X D -A T X D D B 9-3 RT S -A RT S D B 9-7 C T S D B 9-8 C T S -A T 01 69 4 A...
  • Page 70 NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION J1 AN D J2 R X D D B 9 -2 T XD -A T XD R X D -A D B 9 -3 RT S RT S -A D B 9 -7 C T S D B 9 -8 C T S-A T 01 36 4 A...

  • Page 71: Nimp01 Jumpers J14 Through J17 Configuration

    NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION ® D IG IN 1 (+) D IG IN 1 (+) C T SB (+) C T SB (+) D IG IN 1 (–) D IG IN 1 (–) C T SB (–) C T SB (–) H A N D SH A KE D IG ITA L I/O T 01 3 60 A...

  • Page 72: Nimp01 And Nimp02 Cable Connections For Redundant Mfp Modules

    NIMP01/NIMP02 TERMINATION MODULE CONFIGURATION R S -2 3 2 -C P O R TS N K TU 0 2 N K TU 1 2 IM M FP ?2 S ER IA L L IN K N IM P 0 1 L IN K B FO R STAT IO N S P 11...
  • Page 73 Index Abbreviations.............. 1-5 Error codes ............5-1, A-2 Associated documents ..........1-4 Error mode ..............4-4 Example applications ........1-2, C-5, D-5 Execute mode .............4-4 Cables Controlway............3-8 Module bus ............3-8 Faceplate .............1-2, 4-2 Termination module ....... 1-4, 3-9, D-5 Function blocks ............1-1, 4-4 Termination unit ........
  • Page 74 ® Index (continued) Latching screws ............3-10 Quick reference information ........A-1 LEDs 1 through 8 ........1-2, 4-2, 5-10, A-2 Startup sequence ..........4-1 Redundancy ............... 2-4 Status .............1-2, 4-2 References ..............1-4 RS-232-C..........1-6, 5-8, C-5, D-5 RS-485 ............1-6, C-5, D-5 Maintenance schedule ..........6-1 Manual content ............1-3 Module bus ..............3-8 Serial port troubleshooting..........
  • Page 75 Telefax 65-292-9011 Telefax 49-69-799-2406 Form WBPEEUI230019A0 Litho in U.S.A. 897   Copyright © 1997 by Elsag Bailey Process Automation, As An Unpublished Work     ® Registered Trademark of Elsag Bailey Process Automation ™ Trademark of Elsag Bailey Process Automation...
