Mitre/bevel cut
This cut is executed in the same way as a mitre cut and bevel cut.
The board can also be mitred when executing the bevel cut.
Falzschnitt
Tiefenausschnitt
Rebate and section cut-outs
• Transfer the relevant dimensions to the foam board and position the board on the
bearing rail (no. 8). Extract the cutting bow (no. 6) to the desired rebate
measurement and hold it in place. The measurement can be read on the scale
(no. 10) on the lower angled profile of the cutting bow (no. 6).
Guide the board to the left until the wire has reached the end of the marking
and then pull the wire from the board.
• When making a section cut-out repeat the previously described process,
but start by guiding the wire through the board at the desired point up to the
marking. When this area has been reached the panel is offset to the left and
the cutting bow is removed from the board again.
