Laser Printer WL-660 Series for Windows
Quick Setup Guide
First read this Quick Setup Guide to set up your printer and prepare your computer for the
printer.
CAUTION
This printer has been designed specially for Windows 3.1. It cannot work in a DOS
environment such as MS-DOS.
Action 1: Check the Supplied Items
After taking the printer out of the carton and removing the packing materials, make sure that
the following items are not damaged and none are missing:
• Printer
• Drum unit
• 3.5" floppy disks for Windows
• Quick setup guide (this guidebook)
NOTE
You will need to purchase an interface cable that matches the interface of your computer. If
you do not know what cable you need, consult your dealer or reseller.
The product names in this guidebook are trademarks or registered trade marks of each manufacturer. The specifications are subject to change without notice.
©1995 Brother Industries, Ltd.
• Multi-purpose sheet feeder
• Starter Toner cartridge
NOTE: This is a starter toner cartridge
—expected yield 1,000 pages.
TN-100 Replacement toner cartridge
—expected yield 3,000 pages
®
• User's guide
®
UL7394001 A Printed in Japan
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WL-660 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Brother WL-660 Series

Summary of Contents for Brother WL-660 Series

  • Page 1 English Laser Printer WL-660 Series for Windows Quick Setup Guide First read this Quick Setup Guide to set up your printer and prepare your computer for the printer. CAUTION This printer has been designed specially for Windows 3.1. It cannot work in a DOS environment such as MS-DOS.

  • Page 2: Action 2: Install The Toner Cartridge/Drum Unit

    Open the top cover. Open the drum cover by pushing the two blue tabs in toward the center of the unit and lifting the cover toward you. Install the drum unit into the printer. Make sure that you grasp the marks.
  • Page 3 English Unpack the toner cartridge and gently rock it from side to side well before installing. Then, remove the protective parts. ( CAUTION DO NOT MOVE THE SHUTTER LEVER UNTIL THE CARTRIDGE IS INSTALLED. Install the toner cartridge into the drum unit.

  • Page 4: Action 3: Load Paper Into Your Printer

    English Action 3: Load Paper into Your Printer Install the paper support into the multi- purpose sheet feeder. ( Install the sheet feeder into the printer. Open the multi-purpose sheet feeder cover. Load paper into the multi-purpose sheet feeder. NOTE The feeder can hold up to 200 sheets of plain paper or up to 10 envelopes.
  • Page 5 English The printer can handle paper that has the following specifications: Paper Type Cut sheet A4, Letter, Legal, B5, A5, 3”x5”, Executive, Custom size (70-216 x 127-356 mm 2.75”-8.5” x 5”-14”) Envelopes DL, C5, COM-10, Monarch Organizer Day-Timer 70-216 x 127-356 mm 2.75”-8.5”...
  • Page 6 English Action 4: Connect Your Printer and Computer You must connect the printer to your computer using an interface cable. A parallel cable is used for this connection. Make sure that the power cord is unplugged before connecting or disconnecting the interface cable.
  • Page 7 English Action 5: Plug in the Power Cord and Turn on Your Printer Plug the power cord into the AC power outlet. NOTE This printer has no power switch. The printer has a sleep mode that allows the printer to automatically reduce power consumption when not in use.
  • Page 8 IBM PC or compatible with 80486 SX or higher microprocessor Parallel interface (or printer port) 4 MB or more of memory 10 MB of space available on your hard disk for the printer driver and all fonts Microsoft Windows 3.1/3.11 CAUTION This printer has been designed specially for Windows 3.1.
  • Page 9 The Setup program makes the installed printer driver default. The Setup program automatically sets the printer port to the parallel interface, LPT1. The Setup program adds changes to the SYSTEM.INI file. It is necessary to restart Windows so that the changes become effective and the installed bi-directional parallel communications device driver can take effect.
  • Page 10 English Action 7: Set Print Options of Your Printer Before you print documents, set the print options of your printer as follows: 1. Make sure that Windows is restarted immediately after running the Setup program. 2. Open Control Panel in the Main group window.
  • Page 11 5. Choose OK or press the Enter key. The printer starts printing the document. If any problem should occur during printing, the dialog box appears and prompts you to take an appropriate action. For more information about choosing print options from within your application software, see...
  • Page 12 English Shipment of the Printer If for any reason you must ship your Printer, carefully package the Printer to avoid any damage during transit. It is recommended that you save and use the original packaging. The Printer should also be adequately insured with the carrier.
