HD-AVS Panoramic
Bullet Camera
Quick Start Guide
Table Of Contents
Features and Specifications
A.
Overview
B.
Cable Interface
Camera Installation
A.
Installation Steps
B.
Lens Adjustment
C.
Waterproofing Connectors
FAQ and Lightning Protection
A.
Dip Switch Settings
B.
FAQ
www.icrealtime.com
IMPORTANT SAFEGUARDS AND WARNINGS
Electrical Safety
All installation and operation here should conform to your local electrical safety codes. The
power shall conform to the requirement in the SELV (Safety Extra Low Voltage). Please check
product specifications for power requirements. We assume no liability or responsibility for all
the fires or electrical shock caused by improper handling or installation. We are not liable for
any problems caused by unauthorized modification or attempted repair.
Transportation Security
Care must be given to avoid heavy stress, violent vibration or water damage during
transportation, storage and installation.
Installation
Do not apply power to the camera before completing installation. Please install the proper
power cut-off device during the installation connection. Always follow the instruction guide the
manufacturer recommended.
Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers. We are
not liable for any problems caused by unauthorized modifications or attempted repair.
Environment
This series network camera should be installed in a cool, dry place away from direct sunlight,
2
inflammable, explosive substances and etc. Please keep it away from the electromagnetic
2
radiation object and environment. Please make sure the CCD (CMOS) component is out of the
radiation of the laser beam device. Otherwise it may result in CCD (CMOS) optical component
damage. Please keep the sound ventilation. Do not allow the water and other liquid falling into
3-4
the camera. Lightning-proof device is recommended to be adopted to better prevent lightning
4
damage. The grounding studs of the product are recommended to be grounded to further
enhance the reliability of the camera.
4
Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily
5
maintenance work. Do not touch the CCD (CMOS) optic component. You can use the blower to
6
clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is
too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device. Please put the dustproof cap to protect
the CCD (CMOS) component when you do not use the camera.
Accessories
Be sure to use all the accessories recommended by manufacturer. Before installation, please
open the package and check all the components are included. Contact your local retailer ASAP
if something is broken in your package.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IC Realtime HD-AVS
Summary of Contents for IC Realtime HD-AVS
- Page 1 fires or electrical shock caused by improper handling or installation. We are not liable for any problems caused by unauthorized modification or attempted repair. Transportation Security HD-AVS Panoramic Care must be given to avoid heavy stress, violent vibration or water damage during transportation, storage and installation.
- Page 2 This series Panoramic Bullet camera utilizes High Definition 1B. Cable Interface Advanced Video System (HD-AVS) technology, See Figure 1-1 for cable interface identification. Outputs may vary HD-over-coaxial cable video standard that allows long-distance, depending on model. HD transmission of video, audio, and control functions. The panoramic technology allows the multiple lens on the camera to DC Power input (please see your specific model’s power...
- Page 3 2A. INSTALLATION STEPS Step 1 Place the installation map on the mounting surface in accordance to the camera position. Drill the holes and install the expansion screws. If necessary, drill a hole for the cable exit. Step 2 Thread the cables through the mounting surface if necessary or use the side exit routing on the base of the camera .
- Page 4 Sun Shield: Loosen the top screw to slide the sun shield forward and 2C. Waterproofing Connectors back depending on the lighting requirements. See Figure 2-4. For outdoor installations, waterproofing the connectors is necessary. See Figure 2-6. Figure 2-4 2B. OSD and Dip Switch Locate the panel on the bottom of the camera as shown in Figure 2-6.
- Page 5 3A. DIP Switch Settings 3B. FAQ Check whether the power supply is Output ● Dip Switch 1 Dip Switch 2 properly connected. mode No image after the Check recorder video format and ● resolution compatibility with Camera Device is powered on Check whether the main power and ●...
