- Page 1 PLEATED BLIND SL20M plissé SL22M plissé ® ScreenLine double-glazed unit 20 mm • 22 mm...
- Page 2 The ScreenLine ® SL20M or SL22M pleated blind with motor inside the head rail for incor- poration within a double-glazed unit, is manufactured in accordance with high technical specification and production standards. The blind raising / lowering functions are achieved by way of an encoder motor that per- mits a constant speed resulting in a guaranteed synchronized function for multiple blinds.
-
Page 3: Technical Features
technical features the fabric to be nearer to the extremities, guaranteeing better blind stability. The electrical system incorporates a polarity inverter allowing the raise and lower function of all the connected blinds to be fully synchronized using only two wires. A mechanical end-stop incorporated within the head-rail, ensures a safety stop of the blind at the lowest position. - Page 4 PLEATED BLIND SL20M plissé SL22M plissé Performance characteristic of the Verosol ® fabric Pleated Verosol ® Solar Light Solar Solar Light Fabric reflection % reflection % absorbing % transmission % transmission % Performance characteristic of the Vanity fabric Pleated Vanity...
- Page 5 ScreenLine...
-
Page 6: Technical Drawings
SL20M plissé technical drawings comprehensive drawing with component codes SL1145 SL1844 Sliding tube cap SL1680 Internal motor with encoder Adhesive plastic tape 12 mm SL1148 Cord fixing ring SL1817 Head rail (painted) SL1052 SL1850 Calibrated tube Tube support SL20-22M SL1818... - Page 7 SL1052 Tube support SL20-22M Calibrated tube SL1819 Extruded open spacer bar 22x6,5 mm SL1856 - SL1857 End stop RH End stop LH SL1217 ScreenLine plastic label SL1197 Bottom rail cover SL1820 Plastic corner key SL1538 22 mm Bottom rail (painted)
- Page 8 Glass W 14 mm PLEAT EXTRUDED “U” SPACER BAR EXTRUDED “L” SHAPED SPACER BAR Glass W 14 mm PLEAT EXTRUDED “U” SPACER BAR EXTRUDED “C” SPACER BAR ScreenLine...
- Page 9 SL20M plissé SL22M feasibility plissé Width cm 30 35 40 45 50 60 70 80 90 100 110 120 130 140 150 Feasible Not feasible...
- Page 10 • pleated blind with corner keys assembled to the upper spacer • 2 No. L-shaped spacer bars (height) for the system SL20M plea- ted; 2 No. C-shaped spacer bars for the system SL22M pleated • 1 No. bottom U-shaped spacer bar (width) •...
- Page 11 assembly instructions Line assembly Pass the first glass through the washer either on its base or on its height. Position the assembled kit on the first glass, ensuring that the head rail is on the top or on one side. During this operation, it is recommended great care is taken with the integral blind, in order to avoid any dirt or damage of the fabrics.
- Page 12 assembly instructions Second sealing Raise the blind completely apply the final seal, in accordance with EN1279-2 regulation. The secondary sealant should be applied ensuring that the area around the silicone tubes is completely filled either by the auto- matic sealing machine or by hand. The silicon tubes should remain straight and not damaged.
- Page 13 Transport and storage For transport and storage procedures please check the recom- mendations contained in the relevant part of the ScreenLine ® removal of the silicon tubes Technical Catalogue.
- Page 14 SL1807 Control unit This unit is used to control the polarity inversion necessary for the correct function of the motor, which would not be realised when using normal switches. Each control unit can control one blind, or can simultaneously control a group of up to four blinds, depending on the requi- rements of the system.
- Page 15 SL1868 Power supply This power supply unit has been specially developed for the SL27M motor. It comprises two external brackets for wall fixing and two internal terminal blocks – one for the main’s power supply connection and the other for the 24V dc output. It can supply up to a maximum of 4 motors.
- Page 16 Function of the blind The system SL20M – SL22M pleated must be connected to a power supply sufficient to ensu- re a constant 24V dc supply to all the connected motors. The electronic card, contained inside the blind, controls the several functions, one of which controls the stop position corresponding to the end stop of the top and bottom positions.
- Page 17 diagrams electric • Remote radio control should also be used in conjunction with a dedicated ‘control unit’. The following selection of wiring diagrams indicates the wide varietyof possible combina- tions. To raise/lower the blind, by pressing the switch continuously, the speed will change from the slow speed to the fast speed for raise/lower.
- Page 18 ScreenLine...
- Page 19 ScreenLine...
- Page 20 ScreenLine...
- Page 21 ScreenLine...
- Page 22 ScreenLine...
- Page 24 ® Pellini general sale terms and conditions 1. OVERALL The general sale terms and conditions specified below (“General Sale Terms and Conditions”), are an integrated part of the order and/or order confirmation regarding the products and/or services (“Order” and “Order Confirmation”) submitted to and supplied by Pellini S.p.A. (“Company”). Therefore the order is accepted by the company and placed by the purchaser (“Purchaser”) in compliance with the General Terms which - unless otherwise agreed and undersigned by the Company - must be deemed to prevail over the various clauses and conditions referred to by the Purchaser.
- Page 25 PLEATED BLIND SL20M plissé SL22M plissé 10. FORCE MAJEURE Should the Company be faced with the impossibility to carry out the delivery within the agreed terms, due to circumstances beyond its control such as, by way of illustration and not exhaustive: war, governmental restrictions, strikes or lockouts, work force demonstrations or other general or local events;...
