INSTRUCTION BULLETIN
NOTE: DO NOT DISCARD the Parts List from the Instruction Bulletin. Place the
Parts List in the appropriate place in the machine manual for future
reference. Retaining the Parts List will make it easier to reorder
individual parts and will save the cost of ordering an entire kit.
NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials.
Installation instructions for kit number 9020156 (T17 machines NA serial numbers 000000- 010999 /
EU serial numbers 0000- 0330) / 9014965 (T17 machines NA serial numbers 011000-
EU serial numbers 0400-

SYNOPSIS:

This kit contains the parts needed to install the optional rollout battery kit on T17 scrubbers /
M17 sweeper- scrubbers.
Please follow step-by-step instructions.
SPECIAL TOOLS / CONSIDERATIONS: NONE
(Estimated time to complete: 1 hour)

PREPARATION:

1. Park the machine on a clean level surface,
turn off the machine, set the parking brake,
and remove the key.
FOR SAFETY: Before leaving or servicing
machine, stop on level surface, turn off
machine, set parking brake, and remove key.
2. Disconnect the battery cable from the
machine.
WARNING: Always disconnect battery
cables from machine before working on
electrical components.
IB 9012976 (07- 2016)
) (All M17 machines)
PROTECT THE ENVIRONMENT
Please dispose of packaging materials, used machine components
such as batteries and fluids in an environmentally safe way according
to local waste disposal regulations.
Always remember to recycle.
3. Remove the battery from the machine.
FOR SAFETY: When servicing machine, use a
non- conductive battery removal device, use a
hoist and adequate assistance when lifting
batteries, follow site safety guidelines
concerning battery removal, and battery
installation must be done by trained
personnel.
No. 9012976
Machine: T17 / M17
Published: 07- 2016
Rev. 01
/
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9020156 and is the answer not in the manual?

Questions and answers

Related Manuals for Tennant 9020156

Summary of Contents for Tennant 9020156

  • Page 1 NOTE: Numbers in parenthesis ( ) are reference numbers for parts listed in Bill of Materials. Installation instructions for kit number 9020156 (T17 machines NA serial numbers 000000- 010999 / EU serial numbers 0000- 0330) / 9014965 (T17 machines NA serial numbers 011000-...
  • Page 2 INSTALLATION: 2. Use one M5 socket screw (15) and one M5 hex nut (16) to install the limit switch (14) onto NOTE: The rollout battery channel (1) weighs the rollout battery channel (1). (Fig. 1) approximately 85 lbs (39 kg). Assistance is required for lifting the rollout battery channel.
  • Page 3 FIG. 2 4. Use three M8 flat screws (3), three flat 5. Use four M8 hex screws (13) to install the washers (4), and three M8 hex nuts (5) to rollout battery assembly assembled in the install of the three plastic plates (2) into the previous steps into the battery compartment.
  • Page 4 6. Connect the main wire harnes to the rollout battery limit switch (14). (Fig. 3 / Fig. 4) FIG. 3 IB 9012976 (07- 2016)
  • Page 5 FIG. 4 IB 9012976 (07- 2016)
  • Page 6 LCD display. 8. Install the rollout battery door plate (17) onto the rollout battery assembly. (Fig. 2) Bill Of Materials For Battery Rollout Kit, DI [T17] - 9020156 / Battery Rollout Kit, DI [T17] - 9014965 Tennant Part No.
