Step 11 - Mounting the unit to the wall.

RECOMMEND

Wall Mount Kit

Mounting Screw (H15)

Drywall Anchors (H16)

• Using a drill and a small drill bit, drill a hole through the hole in the angle block (H13) and through back panel.

• Place unit in desired location on wall and mark hole locations on wall.

• Drill holes in marked spots on wall and insert drywall anchors (H16). NOTE: A drywall anchor is not necessary

if the mounting screw will be screwed directly into a stud.

• Mount unit to wall, using mounting screws (H15).

Pg 12 of 24

WARNING:

BEFORE CUTTING OR DRILLING INTO ANY WALL SURFACE, VERIFY THE LOCATION OF ELECTRICAL,

PLUMBING AND GAS LINES. CUTTING ANY OF THESE MAY CAUSE SERIOUS INJURY.

• It is imperative that the unit be fastened to the wall for safety and stability.

angle blocks (H13)

H 15

H 13

1/4 in. drill bit

for drywall anchor

1/8 in. drill bit

for direct stud
