- Page 1 SR515ac Quick Start Guide...
-
Page 2: Installation
Installation 1. Connect your gateway to the incoming service wall jack: If an RJ45 cable is included with your gateway, connect one end to the DSL port on the gateway and connect the other end to the wall jack. If a splitter is included with your gateway, connect one end of the splitter to the DSL port of the gateway and connect the other ends to the wall jacks: one for the phone jack and one for the Internet service. - Page 3 COAX 5 min...
-
Page 4: Led Indicators
LED Indicators The LEDs on the SR515ac can assist you in better understanding the current state of your gateway. Legend: Blinking POWER LAN 1-4 WLAN INTERNET DSL sync in progress DSL sync acquired and gateway online Gateway online and data transfer in progress... -
Page 5: Quick Gateway Configuration
Quick Gateway Configuration Warning: Do not press the Reset button unless you want to clear the current settings. The Reset button is in a small circular hole on the rear panel. If you want to restore the default settings, insert a thin wire (such as a paper clip) into the hole, press the Reset button gently for 1 second, and then release the button. - Page 6 Note: Your service provider may use other settings. Please contact your provider for login information. Configuring the WAN manually If the automatic connect process is unsuccessful, refer to the Advanced Setup > Layer 2 Interface WAN Services sections of the SmartRG SR3xx - SR5xx Gateway User Manual to manually establish a connection.
- Page 7 WiFi Setup Two methods, WPS and Manual, are available for WiFi setup. Perform the steps on this page first, and then follow the instructions for the applicable method. 1. In the left menu, click Wireless and then click 2.4 GHz Band 5 GHz Band.
- Page 8 4. Click Apply/Save. 5. Continue with the steps for the method you prefer.
- Page 9 WPS Method If the device you wish to connect to the Internet via your gateway supports the WPS secure WiFi connection method, follow these steps. 1. In the left navigation bar, click Wireless > the wireless band you want to configure, and then click Security. 2.
- Page 10 Manual Method Set up your gateway’s parameters first, then follow these steps. 1. In the left navigation bar, click Wireless > the wireless band you want to configure, and then click Security. 2. Scroll down to the Manual Setup AP section.
-
Page 11: Optional Wall Mount
Optional Wall Mount Using a Phillips-head screwdriver, remove the mount from its Gateway Front present location on the bottom of the gateway. Slide the mount onto the back of the gateway. Tighten the screw located in the bottom of the mount. Using the template below, mount the two included screws to 1/16”... -
Page 12: Additional Support
Predefined wireless settings If you change the preset wireless settings WiFi network name (SSID) Network key (password) Additional Support If you require further instructions, please contact your local ISP support. SmartRG Inc, an ADTRAN company. All Rights Reserved. © 2020...
