Moxa Technologies UC-5100 Series Manual

Industrial Computers
UC-5100 Series
Communication-centric RISC computing platform
for industrial automation
Introduction
The UC-5100 Series embedded computers are designed for industrial
automation applications. The computers feature 4 RS-232/422/485
full signal serial ports with adjustable Pull-High/Pull-Low resistors,
dual CAN ports, dual LANs, 4 digital input channels, 4 digital output
channels, a SD socket in a compact, front-end access housing.
To fulfill various industrial applications, the UC-5100 Series computing
platform provides models with dual CANopen protocol supported CAN
ports and mini PCIe socket for wireless connection featuring a dual
SIM design for network redundancy.
Appearance
UC-5101
1
›
ARMv7 Cortex-A8 1000 MHz processor
›
Dual auto-sensing 10/100 Mbps Ethernet ports
›
4 software-selectable RS-232/422/485 ports supporting all
signals
›
Dual Industrial CAN 2.0 A/B protocol supported
›
Moxa Industrial Linux with 10-year superior long term support
›
Mini PCIe socket for Wi-Fi/Cellular module
›
Micro SD socket for storage expansion
›
Supports TPM v2.0 (optional)
›
-40 to 85°C wide temperature range and -40 to 70°C with LTE
enabled
The UC-5100's vertical DIN-rail form factor makes it easy to install
the computers in a small cabinet. This space-saving solution also
facilitates easy wiring, making the UC-5100 a great choice as front-end
embedded controllers for industrial applications.
Furthermore, all the models are equipped with MOXA's industrial grade
Linux for users to enjoy its superior long term support operating
system as well as the optimized software features.
