Troubleshooting - Fimap ORBITIZER Use And Maintenance Manual

CODE QTY
453208 1
453410 1
453411 1
453412 1
This chapter lists the most common problems linked with the use of the machine. If you are unable to resolve the problems with the information
given here, please contact your nearest assistance center.
PROBLEM
The main switch is OFF.
An alarm sequence appears on the control display when
it is switched on.
THE MACHINE
The battery is not correctly inserted into the machine.
DOES NOT START
The battery charge level is low.
The charger cable connector is not correctly plugged into
the socket on the base of the battery charger.
The battery charger power cable plug is not properly
plugged into the mains socket.
THE BATTERY IS
NOT PROPERLY
The characteristics of the power supply network do not
FITTED
correspond with those required by the battery charger.
The LEDs of the battery charger blink repeatedly.
THE MACHINE
Check the battery charge level; check the symbol on the
HAS A VERY LOW
control display.
WORK AUTONOMY
THE AMOUNT The quantity of detergent solution present in the solution
OF DETERGENT tank is not suitable for the type of work to be carried out.
SOLUTION ON
THE BRUSH
The nozzles on the brush head body are blocked.
HEAD BODY IS
INADEQUATE
The machine does not start.
Not enough detergent solution comes out.
THE MACHINE
The pad has not been correctly inserted into the machine.
DOES NOT CLEAN
CORRECTLY
The type of pad in use is not suitable for the dirt to be
tackled.
The pad is excessively worn.
The detergent being used is not suitable.
EXCESSIVE FOAM
PRODUCTION
The floor is not very dirty.
WIDTH LENGTH
[cm] [cm]
34 16
34 16
34 16
35 16

TROUBLESHOOTING

POSSIBLE CAUSE
RED ABRASIVE PAD
BROWN ABRASIVE PAD
WHITE ABRASIVE PAD
MICROFIBRE PAD
Check that the main switch is on; if not, press it.
Stop the machine immediately, and contact a specialized
service center.
Insert the battery correctly, see "INSERTING THE
BATTERY INTO THE MACHINE" on page 15
If the battery charge level is critical, carry out a full
charging cycle. See "RECHARGING THE BATTERY" on
page 15
Try reconnecting the charger cable connector to the
socket on the base of the battery charger.
Connect the battery charger power cable plug to the
mains socket.
Check that the electrical characteristics on the battery
charger plate are the same as those of the mains supply
system.
Referring to the use and maintenance manual for the
battery charger, check what the flashing lights on the
charger during battery charging mean.
If the battery charge level is critical, carry out a full
charging cycle. See. "RECHARGING THE BATTERY" on
page 15
Fill the solution tank; see "FILLING THE SOLUTION
TANK" on page 16.
Clean the nozzles and the entire machine water system;
see "ROUTINE MAINTENANCE" on page 18
Read the section "THE MACHINE DOES NOT START".
See the section "THE AMOUNT OF DETERGENT
SOLUTION ON THE BRUSH HEAD BODY IS
INADEQUATE".
Position the pad correctly.
Check that the pad selected is suitable for the work to
be carried out; for help, contact the nearest technical
assistance center.
Check the state of wear of the brush and, if necessary,
replace it.
Check that a low foam detergent has been used.
Dilute the detergent more.
20
NOTES
SOLUTION
