Technical specifications

Art. UT2010

Product height (mm)
Product depth (mm)
Coating material type
COMPATIBLE SYSTEMS
Simplebus 2 audio/video with
power supply unit art. 1210/1210A
Simplebus 2 audio/video kit with
power supply unit art. 1209
Simplebus 2 audio with
power supply unit art. 1210/1210A
AUDIO SPECIFICATIONS
Technologies implemented
ELECTRICAL SPECIFICATIONS
Type of power supply
Power supply voltage
Absorption in standby (W)
Maximum absorption (W)
HARDWARE CHARACTERISTICS
Number of buttons (no.)
Number of inputs (no.)
Number of outputs (no.)
Communication port
Loudspeaker volume
Backlighting brightness
PROGRAMMING MODE
Manual (by means of Dip Switch)
ViP Manager software
ENVIRONMENTAL AND CONFORMITY
IP protection rating (when installed)
IK anti-vandal protection rating
Operating temperature (°C)
Operating humidity (max RH - %)
Environmental class
Conformity and Certifications
MAIN FUNCTIONS
Number of auxiliary relays (no.)
Input for local key button
Input for door open signal
System status visual indications
System status audio indications
System status voice synthesis
6
GENERAL DATA
Type Modular
90
Product width (mm) 100
35
Product colour Black RAL9005, Transparent, Aluminium
Product weight (g) 275
Polycarbonate, Aluminium alloy
Flush mounting Yes, with specific accessory
Surface mounting Yes, with specific accessory
Yes
Yes
Yes
Microphone MEMS digital audio sensor, omnidirectional
Loudspeaker 28 mm (Ø), 8 Ohm, 1W (2)
Full-Duplex
Power supply via video entry bus
33 VDC
1.5
3.5
Call type Buttons
Type of buttons Mechanical
2
Backlighting colour White, Off
Terminals L L V+ V- COM NC NO SE+ SE-/GND RTE TX- TX+ RX- RX+
1
2
Output type Micro-USB
Relay (C-NO-NC, 4A@12-24 VAC/VDC, inrush current 10A)
Twilight sensor Yes
SETTINGS
Yes
Mic volume Yes
Yes
Yes
Yes
SPECIFICATIONS
IP65
IK08
-25 to 55
25 to 95
IV
RoHS II - 2011/65/EU (EN 50581:2012), EMC 2014/30/EU (EN 61000-6-
1:2007, EN 61000-6-3:2007+A1:2011)
Lock-release Yes
1
Yes
Yes
Yes
Yes
Yes
