UNILITE SLR-1450 Quick Start Manual

FEATURES
High power 1450 lumen white COB LED, 6500k
ƒ
With 150 lumen 6500k white LED flashlight
ƒ
Plus 45 lumen Red and Red flash modes
ƒ
Powerful 'LG' 3.7v 5000mAh 21700 Li-ion battery
ƒ
Super tough copolymer and aluminium construction
ƒ
180˚ rotating handle/stand with carabiner snap hook
ƒ
Strong magnets within the stand
ƒ
Glow-in-the-dark strip around reflector for extra visibility
ƒ
IPX5 water resistant
ƒ
4 Battery level and charging indicators
ƒ
Faster 2A USB-C charging - 3 hour charge time
ƒ
1m high quality USB-C cable included
ƒ
Battery can be removed so a convenient spare can be kept at
ƒ
hand
21700 li-ion battery has its own USB-C port so is easily
ƒ
charged out of the lamp and used as a 1A Powerbank
BATTERY - 3.7v 5000mAh 21700 Li-ion
WEIGHT - 288g
DIMENSIONS - folded H 122.5 x W 50.5 x D 50.5mm
extended H 219 x W 50.5 x D 50mm
ADVICE & IMPORTANT INFORMATION!
ƒ Do not look directly at LEDs.
ƒ Do not operate in direct sunlight or extreme temperature conditions (below -20°C or
above 60°C).
ƒ LEDs can become warm/hot when switched on; do not touch and never place face
down on any surface – risk of fire!
ƒ Do not use the device if there is any visible damage.
ƒ Take care when using USB plug adaptors, check for any damage. Check the charging
output on the plug and DO NOT exceed the stated Max charging input or damage
may occur to the battery and may void the warranty.
ƒ The rechargeable battery will reach full performance after a few complete charging
and discharging cycles.
ƒ To keep the rechargeable battery in optimum condition, it should be recharged every
3-6 months, especially if it is not being used for a long period of time. Always fully
charge batteries before storage.
ƒ Always protect lithium batteries from heat, intense sunlight, fire, water and moisture
– danger of explosion!
ƒ If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin
irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation
persists, seek medical advice. Seek immediate medical assistance if lithium battery
fluid comes into contact with the eyes.
ƒ Children under 12 years of age should only use the product under adult supervision.
ƒ Do not disassemble or attempt to modify the product; this will void the warranty and
can be dangerous. Improper use or modification is not covered under the warranty.
ƒ Take care not to let lenses come into contact with hard/sharp objects, damage/
scratches to lenses will affect light output.
ƒ Do not use the product in the immediate vicinity of flammable materials or gases.
ƒ Before cleaning the product, disconnect the charge cable. Clean with a dry or slight-
ly moist, clean, lint-free cloth and a mild detergent if required. Do not use cleaners
that contain abrasives or solvents.
ƒ This product is water resistant to IPX5 – DO NOT SUBMERGE. If the product has been
subjected to excessive moisture/water the warranty may be void.
ƒ This product has a 1 year standard warranty (or extended to 2 years once registered
online at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and
defects. It does not cover normal wear and tear, modifications, accidental damage or
poor maintenance. Unilite warranties do not cover disposable battery leaks or the use
of incorrect chargers and cables that can damage rechargeable batteries.
ƒ Do not dispose of this device in normal household waste. It must be disposed of via
an authorised electrical appliance disposal centre or at your local waste disposal unit.
ƒ Please re-use or recycle packaging responsibly where possible.
www.unilite.co.uk
ANSI FL1 Standard
Floodlight - High
Floodlight - High
Floodlight - High
Flashlight
Red Flood - High
Red Flood - Flashing
OPERATION
WHITE MODES:- Floodlight High > Floodlight Medium >
Floodlight Low > Flashlight > Off
RED MODES:- High > Flash > Off
[When 'ON' in either WHITE or RED modes, press and HOLD
the button for 3-4 seconds to switch to the other mode]
[If left in any mode for over 3-4 seconds, the next press will turn off]
DIRECT RECHARGING
1. Lift the charging port cover on the side of the lamp.
1. Only use a 5V USB-C cable (max 2A).
2. Plug the USB-C end of the cable into the charge port.
3. Plug the other end of the cable into a USB charging port (do
not exceed 5V-2A charging input or damage may occur. Please
do not use "Fast Chargers" as this can over-load the battery).
4. The 4x battery indicators on the side of lamp will illuminate
and flash to show charging status. Once fully charged, all the
indicators will illuminate continually.
5. If the battery indicators do not illuminate, remove the cable
and try again.
6. Charge Time: 3 hours
7. Make sure the charge port cover is secured back in place.
(PRODUCT CAN BE USED WHILE RECHARGING)
*Warranty void if not used with the specified cable & max charge
input*
RECHARGING THE 21700 BATTERY
You can recharge the 21700 battery outside of the lamp. This
enables a spare to be kept on hand if you require light for an extra
long period. Once plugged in, a Red light will appear on the top
of the battery to confirm charging. Once fully charged it will turn
Green.
21700 POWER BANK
The 21700 battery inside the lamp can be removed and used as a
1A Powerbank via the USB-C port. You will need your own devices
charging cable for this. Plug the USB-C end of your devices
charging cable into the USB-C port. A Blue light will appear on the
top of the battery to confirm your device is being charged.
SLR-1450
1450
43 M 3 H
Lumen
670
30 M 4 H
Lumen
175
15 M 16 H
Lumen
150
53 M 13 H
Lumen
45
-- 11 H
Lumen
45
-- 90 H
Lumen
