NuTone E662E Specification Sheet

E662E RANgE HOOD
For use with External Blowers
The Broan Elite E662E model is part of our new
generation of range hoods: stylish, powerful, and
most of all, quieter than ever.
FEATURES
•
Sleek, classic smooth shell design makes cleaning easy
•
Created to work over high BTU residential grade cooking
equipment
•
Colors available: White or Black durable powder-coated
paint finishes for 30'' and 36'' widths, and Stainless Steel
for 30'', 36'' or 42'' widths
•
Dishwasher safe stainless steel and aluminum filters with
metal latch
•
Recessed bottom and forward filters increase capture
capability
•
Dual 50-Watt halogen lights focus toward the center for
brilliant full cooktop lighting
(MR16 GU10 bulbs not included)
•
External blower options (sold separately) provides exhaust
options ranging from 280 to 1500 cfm
•
Seamless glass-look control
•
Variable delay shut-off feature; 5, 10, 15 or 20-minute
settings
•
Exclusive I-Control™ senses the touch of a finger without
moving parts, smooth design for easy cleaning
•
Self-locking control to avoid accidental operation when
being cleaned
•
Broan Heat Sentry - automatically turns blower to high
speed when excess cooking heat is detected
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario, L5T 1H9 (1-888-882-7626)
REFERENCE QTY.
TYPICAL SPECIFICATION
Range hood shall be Broan Elite E662E.
Unit will have all over smooth design, with no sharp edges.
Finish to be powder-coated paint (brushed finish stainless
steel). It must have a fully enclosed stainless steel bottom
and full stainless steel and aluminum filters.
Range hood to have twin, 50-watt (max.) halogen flood max.
Blower and light shall be operated using a specially-designed,
3-speed control with boost, memorizes last setting, with 5,
10, 15, 20-minute delayed "off''.
External blower options ranging from 280 to 1500 cfm.
Unit shall be U.L. and cU.L. listed.
SPECIFICATIONS
Volts
HZ
Controls
Halogen flood light
Broan Heat Sentry
REMARKS
SPECIFICATION SHEET
HB0041
120
60
3-speed electronic with memory,
plus Boost mode
MR16 GU10, 2 bulbs required,
not included
Yes
Project
Location
Architect
Engineer
Contractor
Submitted by
70F
Date
99043670D
