NuTone E661 Specification Sheet

E661 RANGE HOOD
The Broan Elite E661 model is part of our new
generation of range hoods: stylish, powerful, and
most of all, quieter than ever.
FEATURES
•
Sleek, classic smooth shell design makes cleaning easy
•
Created to work over high BTU residential grade cooking
equipment
•
Colors available: White or Black durable powder-coated
paint finishes for 30'' and 36'' widths, and Stainless Steel
for 30'', 36'' or 42'' widths
•
Dishwasher safe aluminum filters with metal latch
•
Dual 50-Watt halogen lights focus toward the center for
brilliant full cooktop lighting
(MR16 GU10 bulbs not included)
•
New High Flow centrifugal blower wheel provides greater
performance and quieter operation
•
Flush-mounted electro-mechanical controls with
Amber-Yellow LED status lights
•
5-minute off delay
•
Broan Heat Sentry - automatically turns blower to third
speed when excess cooking heat is detected
•
Versatile design allows for a 3¼'' x 14'' horizontal or
vertical discharge
SPECIFICATIONS
Volts
HZ
Amps
CFM (high)
Sones (norm.)
Sones (high)
Controls 3-speed electronic with memory, plus boost mode.
Halogen Flood Light
Broan Heat Sentry
* 550 cfm & 8.5 sones in boost mode.
† 2 bulbs req. (not included).
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario, L5T 1H9 (1-888-882-7626)
REFERENCE QTY.
120
60
2.4
300*
<0.3
3.0*
MR16 GU10 †
Yes
REMARKS
SPECIFICATION SHEET
TYPICAL SPECIFICATION
Range hood shall be Broan Elite E661.
Unit will have all over smooth design, with no sharp edges.
Finish to be powder-coated paint (brushed finish stainless
steel). It must have a fully enclosed stainless steel bottom
and full aluminum filters.
Hood discharge to be 3¼" x 14", horizontal or vertical.
Range hood to have a centrifugal blower and twin, 50-watt
(max.) halogen flood max. Blower and light shall be operated
using a specially-designed, 3-speed control with boost,
memorizes last setting, with 5-minute delayed "off''.
Air delivery shall be no less than 550 cfm. Sound level to be
no greater than 0.3 sones/110 cfm - 3.0 sones/300 cfm - 8.5
sones/550 cfm (boost mode).
Air and sound ratings to be certified by HVI. Unit shall be U.L.
and cU.L. listed.
HVI-2100 CERTIFIED RATINGS comply with the
new testing technologies and procedures prescribed
by the Home Ventilation Institute, for off-the-shelf
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure, based
on tests conducted in AMCA's state-of-the-art
laboratory. Sones are a measure of humanly produced
loudness, based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
50B
Date
99043668B
