Provided accessories

-
Plug A, Plug B
-
Precrimped cables
-
Four fastening screws
-
MicroSD card (installed)
-
MicroSD adapter to SD
-
Diffuse display foil
-
2x 1K1 pullup resistor (for NTC)
-
additional pins for own crimps
Plug A: Molex 43025-0800
PLUG
A1
A2
A
GND
5V
B1
B2
PLUG
B
RX2*
CANH
Version v0.2d
Quickstart Guide
MFD28
Plug B: Molex 43025-1000
A3
A4
A5
AIN4
AIN3
12V
B3
B4
B5
CANL
SHIFT
RX
www.canchecked.de
More information
More information on the display and
other products and accessories you
can find online at:
www.canchecked.de
www.canchecked.de/mfd28/
Crimp: 43020-0001
A6
A7
A8
GND
AIN2
AIN1
B6
B7
B8
TX2*
*
5V
* future
Application
B9
B10
GND
TX
