Model:
BAY-STOVE
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Printed in U.S.A. Copyright 2001,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
GUIDE
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Heat-N-Glo dealer with any
questions or concerns. For the number of your
nearest Heat-N-Glo dealer, please call 952-985-6000.
1
Installers Guide
Underwriters
Laboratories Listed
INSTALLERS

Advertisement

Table of Contents
loading

Summary of Contents for Heat-N-Glo Bay-stove

  • Page 1 Printed in U.S.A. Copyright 2001, Please contact your Heat-N-Glo dealer with any questions or concerns. For the number of your Heat-N-Glo, a division of Hearth Technologies Inc.
  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION READ and UNDERSTAND all instructions carefully These units MUST use one of the vent systems before starting the installation. FAILURE TO FOLLOW described in the Installing the Fireplace section of the these installation instructions may result in a possible Installers Guide.
  • Page 3: Table Of Contents

    Appliance Certification..............6 Installation Codes ................6 High Altitude Installations ............... 6 Section 2: Getting Started ............7 Introducing the Heat-N-Glo Gas Appliances ........7 Pre-installation Preparation ............7 Section 3: Installing the Appliance ........... 9 Step 1 Locating the Appliance ........... 9 Step 2 Installing the Vent System ..........
  • Page 4: Section 1: Approvals And Codes

    Approvals and Codes High Altitude Installations Appliance Certification Installers Guide Certification Heat-N-Glo Quality Systems registered by SGS ICS...
  • Page 5: Section 2: Getting Started

    Getting Started Introducing the Heat-N-Glo Gas Appliances Installers Guide Pre-install Preparation Installers Guide...
  • Page 6 19 1/8 (486mm) 9 9/16 (243mm) VENT COLLARS 6 5/8 (168mm) 17 1/2 (445mm) 11 1/2 (292mm) 25 1/4 (640mm) 30 (762mm) 9 7/8 (251mm) 34 3/8 (873mm) 17 1/4 (448mm) 9 1/2 (242mm) VENT COLLARS TOP GRILLE GLASS DOOR LABELS BEHIND LOWER GRILLE ACCESS FOR GAS...
  • Page 7: Section 3: Installing The Appliance

    ALCOVE INSTALLATION CORNER INSTALLATION 48 MIN. 1 MIN. Installing the Appliance 9 MIN. 3 MIN. Constructing the Chase 48 MIN. 4 MIN. CEILING CAUTION: TREATMENT OF FIRESTOP SPACERS AND (45 MIN. - TOP OF UNIT) 3 MIN. CONSTRUCTION OF THE CHASE MAY VARY WITH THE TYPE OF BUILDING.
  • Page 8 6 3/8 (162mm) 6 1/2 (165mm) 9 5/8 (244mm) 6 3/8 (162mm) 6 5/8 (168mm) 9 5/8 (244mm) SL-90D 6 1/2 (165mm) 17-24 (432-610mm) 5 4/3 (146mm) 11 3/4 (298mm) 6 5/8 (168mm) SL-17/24D SL-06D SL-12D 47 3/4 (1213mm) 35 3/4 (908mm) 23 3/4 (603mm)
  • Page 9: Step 2 Installing The Vent System

    VENT SYSTEM COMPONENTS VERTICAL TERMINATION STORM COLLAR ROOF FLASHING HORIZONTAL HORIZONTAL PIPE TERMINATION SUPPORT PIPE LENGTH WALL FIRESTOP CEILING WALL BRACKET FIRESTOP 90 DEGREE ELBOW Termination Kits SLK-01D SLK-991DA Step 2. Installing the Vent System Installers Guide Identifying Vent Components...
  • Page 12 VENTING WITH THREE (3) 90° ELBOWS H + H FT. (M) FT. (M) FT. (M) 4´ MIN. (1.22m) 2´ MAX. (.6m) 2´ MAX. (.6m) 20´ MAX. (6.2m) 20´ MAX. (6.2m) Rise to Run up to 9 FT. Vertical: Ratio = 2:1 Rise to Run above 9 FT.
  • Page 14: Installing Vent Components

    B. Installing Vent Components STARTING COLLAR STOVE SEALANT BEAD FIRST VENT COMPONENT 1 INCH (25.4mm)
  • Page 15 NOTE: The center of the hole is one (1) inch (25.4mm) above the center of the horizontal vent pipe. WALL BRACKET 10" (254mm) 1" (25.4 mm) WALL STUD 10" (254mm) VENT PIPE WALL BRACKET HEAT SHIELD 8 FT. (2.4m) TRIM HEAT SHIELD IF TOO LONG, ADD TO SHIELD IF TOO...
  • Page 16 JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP NOTE: Keep insulation away from the vent pipe at least 1 inch (25mm). 10" (254mm) 10" (254mm) NAILS (4 REQUIRED) CHIMNEY HOLE RAFTER EXISTING CEILING JOISTS FRAMING MEMBERS CEILING CEILING CEILING FIRESTOP...
  • Page 17: Vent Termination

    C. Vent Termination ROUND CAP TERMINATION PERFORATION CANNOT BE INSIDE THE WALL 7 1/2" (191mm) MINIMUM...
  • Page 18 openable fixed closed J or K 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS NECESSARY TO INSTALL THE VINYL PROTECTOR KIT TO THE TOP OF THE EXTERIOR FIRESTOP (FOR ALL ROUND TERMINATION CAPS).
  • Page 19 HORIZONTAL OVERHANG 2 FT. 2 FT. MIN. VERTICAL MIN. WALL LOWEST DISCHARGE OPENING TERMINATION ROOF PITCH IS X/ 12 H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING NOTE: This also pertains to vertical vent systems in- stalled on the outside of the building.
  • Page 20: Step 3 The Gas Control System

    TIGHTENING GAS LINE MANUAL SHUT-OFF VALVE GAS VALVE FLEX CONNECTOR Step 4. The Gas Supply Line Step 5. Gas Pressure Requirements Pressure requirements for Heat-N-Glo gas appliances are shown in the table below. Pressure Natural Gas Propane Minimum 5.0 inches 11.0 inches Inlet Pressure w.c.
  • Page 21: Step 6 Wiring The Appliance

    BLACK S2 REMOTE SWITCH 3/16” PIGGYBACK CONNECTOR PIGTAIL ON/OFF WHITE T2 SWITCH GAS VALUE RED T1 THERMOPILE THERMOCOUPLE OPTIONAL WALL SWITCH, BLACK S1 THERMOSTAT OR REMOTE Step 6. Wiring the Appliance CAUTION: LABEL ALL WIRES PRIOR TO DISCONNEC- TION WHEN SERVICING CONTROLS. WIRING ERRORS CAN CAUSE IMPROPER AND DANGEROUS OPERATION.
  • Page 22: Step 7 Finishing

    VARIABLE SPEED CONTROL NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE REPLACED WITH TYPE 105 C RATED WIRE. JUNCTION BOX BLOWER RECEPTACLE GROUND TEMPERATURE SENSOR SWITCH BLOWER TEMPERATURE JUNCTION BOX SENSOR SWITCH 110-120 VAC SPEED CONTROL...
  • Page 23: Step 8 Positioning Logs, Ember Material And Glass Doors

    Step 8. Positioning Logs, Ember Material and Glass Doors...
  • Page 24: Positioning The Logs

    POSITIONING THE LOGS...
  • Page 25: Step 9 Before Lighting The Appliance

    Step 9. Before Lighting the Appliance Step 10. Lighting the Appliance Installers Guide After the Installation...
  • Page 26: Section 4: Maintaining And Servicing Your Appliance

    Maintaining and Servicing Your Appliance Appliance Maintenance...
