Heat-N-Glo Tiara I Owner's Instruction Manual
  1. Manuals
  2. Brands
  3. Heat-N-Glo Manuals
  4. Stove
  5. Tiara I
  6. Owner's instruction manual

Heat-N-Glo Tiara I Owner's Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tiara I and is the answer not in the manual?

Questions and answers

James R Dupler
January 23, 2025

how to oil the **** blower

0
1 comments:
Mr. Anderson
May 14, 2025

To oil the blower for the Heat-N-Glo Tiara I, use Anderol 465 Synthetic Bearing Oil. Apply the oil to the blower motor's bearing points as needed to maintain smooth and quiet operation.

This answer is automatically generated

0

Related Manuals for Heat-N-Glo Tiara I

Summary of Contents for Heat-N-Glo Tiara I

  • Page 7 (889mm) 10 1/2 (267mm) 7 (179mm) 15 1/4 18 3/4 (387mm) (478mm) (330mm) Ø6 5/8 (168mm) 21 (533mm) 27 1/8 26 1/8 (688mm) (664mm) 6 7/8 (175mm)
  • Page 8 14 3/4 (375mm) Ø6 5/8 (168mm) 7 1/2 (191mm) 15 1/4 (387mm) 19 3/8 (330mm) (491mm) 29 1/2 (749mm) 43 1/2 (1105mm) 29 1/4 30 1/8 6 7/8 (742mm) (766mm) (174mm)
  • Page 9 16 1/8 (410mm) 9 7/8 (251mm) 4 (101mm) 33 3/8 (848mm) 6 (152mm) 4 5/8 (118mm) 18 1/2 (470mm) 12 1/4 (311mm) 6 (152mm) 36 3/4 (933mm) 9 (229mm) 4 (102mm)
  • Page 11 COMPONENT IDENTIFICA TION (IDENTIFICA TION VERTICAL DES ELEMENTS) TERMINA TION (MITRE VERTICALE) ST ORM COLLAR (COLLIER D’ORAGE) ROOF FLASHING HORIZONT AL TERMINA TION (SOLIN) (MITRE HORIZONT ALE) HORIZONT AL PIPE SUPPORT (SUPPORT CONDUIT HORIZONT AL) PIPE LENGTH (SECTION DE CONDUIT) WALL FIREST OP (COUPE-FEU MURAL)
  • Page 12 6 1/2 in. 6 3/8 in. (165mm) (162mm) 9 1/4 in. (235mm) 6 1/2 in. (165mm) 9 5/8 in. 6 3/8 in. (244mm) 6 5/8 in. (162mm) (168mm) SL-45D 6 5/8 in. (168mm) 9 5/8 in. (244mm) SL-90D 17-2 4 in. (432-610mm) 6 1/2 in.
  • Page 14 FIREBOX (FOYER SUPERIEURE) ROUND BAFFLE (D FLECTEUR È ROND ) SQUARE BAFFLE (D FLECTEUR È CARRÉ)
  • Page 20 ST ARTING COLLA R (COLLIE R D E DÉP ART ) ST OVE SEALANT BEAD 3/8" (FILE T D E C IMENT RÉFRACT AIRE 9,5 mm) FIRST VENT COMPONENT (PREMIÈRE SECTIO N DU CONDUI T DE VENTILA TION) 1 INCH (25.4 mm)
  • Page 21 WALL BRACKET (SUPPORT MURAL) WALL STUD (MONT ANT DU MUR) 8 ft (240cm) 1 INCH MIN. (25.4mm) VENT OUTLET (ORIFICE D’ÉCHAPPEMENT)
  • Page 22 10" (254 mm) 10" (254 mm) 1" (25.4 mm) VENT PIPE (CONDUI T HE AT SHIELD/ TRIM HE AT SHIELD IF TO O L ONG , ÉCRAN THERMIQUE ADD TO SHIELD IF TO O SHORT ./ COUPER L’ÉCRAN THERMIQUE S’IL EST TRO P L ONG ET LE RALLONGE R S ’IL EST TROP COURT .
  • Page 23 CHIMNEY HOLE 10 IN . (TROU POUR (254mm) 10 IN . LE CONDUIT) (254mm) CEILING (PLAFOND) EXISTING CEILING JOISTS NEW FRAMING MEMBERS (SOLIVES DE LA CHARPENTE) (TASSEAUX NEUFS)
  • Page 24 JOIST/ SOLIV E CEILING/ PLAFOND NAILS (4 REQUIRED) / CEILING FIREST OP/ CLOUS (4) COUPE-FEU DE PLAFOND NAILS (4 REQUIRED) / CLOUD (4) RAFTER/ CHEVRON CEILING/ PLAFOND CEILING FIREST OP/ COUPE-FEU DE PLAFOND...
  • Page 25 ROUND CAP TERMINA TIO N MITRE RONDE (CHAUD) PERFORA TION CANNOT BE INSIDE TH E W ALL (LA PERFORA TIO N N E PEUT PA S SE TROUVER DANS LE MUR) 7 1/2” (191mm) MINIMUM TRAPEZOID CAP TERMINA TION MITRE TRAPÉZOÏDALE 7 1/4”...
  • Page 26 OPENABLE FIXED CLOSED (OUVRABLE) (CONDAMNÉE) J o r K (J ou K)
  • Page 28 HORIZONT AL OVERHANG 2 F T. MIN. (SURPLOMB) (61 cm ) 2 F T. MIN. (61 cm ) LOWEST VERTICAL WA LL DISCHARGE (MUR VIERTICAL ) OPENING (ORIFIC E ’ECHAPPEMENT LE PLUS BAS) TERMINA TION CAP (MITRE) ROOF PITC H A I X /12 (PENT E D U T OI T D E X /12) H ( MIN.
  • Page 29 3/8” (10mm)
  • Page 30 USE A WRENCH ON SHUT -OFF VA LV E MANUAL WHEN TIGHTENING SHUT -OFF VA LV E GAS LINE (ROBINET MANUEL) (UTILISER UNE CL É SUR LE ROBINET POUR SERRER CONDUITE DE GAZ) GA S V AL VE (VANNE DE COMMANDE) FLEX CONNECT OR (CONNECTEUR...
  • Page 32 THERMOCOUPL REMOTE SWITCH PIGT AI L THERMOPILE (QUEUE DE COCHON DE COMMANDE A D IST ANCE) (MARCHE ) (ARRÊT) ON/OFF SWITCH GAS VA LV E (INTERRUPTEUR (VANNE DE COMMANDE) MARCHE/ARRÊT) OPTIONAL WALL SWITCH, THERMOST AT OR REMOTE (INTERRUPTEUR MURAL EN OPTION THERMOST AT OU COMMANDE À...
  • Page 33 SWITCH BOX (BOITE DE INTERRUPTEUR REAR SHIELD (ECRAN ARRIERE) BLOWER (VENTILA TEUR) SHUT -OFF VA LV E & FLEX CONNECT OR BLOWER BRACKET ROBINET DE LA VANNE (SUPPORT DU VENTILA TEUR) ET RACCORD FLEXIBL E VARIABLE SPEED CONTROL (COMMANDE DE VITESSE VARIABLE) BL K BL K...
  • Page 34 COMBUSTIBLE 72” MIN. PROJECTIO (1829m m MIN.) (PROJECTIO COMBUSTIBLE)
  • Page 35 EMBERS (BRAISES)
  • Page 36 Tiara I Model: LOG PLACEMENT INSTRUCTIONS (Log Set Assembly 844-9320) CAUTION: Logs are fragile! Carefully remove the logs from the packaging. LOG #1: Place Log #1 behind the back of the burner with notch over the pilot. Slide log to the left and make sure that the log is touching the back of the burner.
  • Page 37 Tiara II Model: LOG PLACEMENT (Log Set Assembly 844-9330) INSTRUCTIONS CAUTION: Logs are fragile! Carefully remove the logs from the packaging. LOG #1 : Place log #1 in back of the stove so the notch fits over the pilot and the back of the log hits the back of the stove.
  • Page 38 LOG # 3: Place #3 against the tab on the right wall and the tab on the burner pan. Make sure no burner ports are covered in the front.
  • Page 41 3/8” (10mm) EMBERS (BRAISES)
  • Page 43 ATTENTION INSTALLER: PLEASE RETURN THESE INSTRUCTIONS TO THESTOVE OW NERW HEN INSTALLATION IS COMPLETED.
