3.1 Before Operating Unit
BEFORE operating your new SA
Become thoroughly familiar with the operation and maintenance of the unit before using and note the
information on the control panel and rear of the unit. Only persons trained in its use should operate
the unit.
Check that the voltage supply is as printed on the rating plate fitted to the back of the SA
Warning! Always electrically isolate the SA
carrying out any cleaning, maintenance or repairs. Electrical isolation of the
SA
3.2 Unit Set Up
• Connect the desired collection system securely in place on the bracket(s) fitted to the
side of the unit. More detail can be found later in this section.
Connect the desired equipment to the patient inlet tube on the collection container
•
top.
• Connect the unit to the power supply, check label on rear of unit for correct ratings.
Do not obstruct access to the mains power supply, and ensure the power cable does
not create a trip hazard or is subject to damage. Ensure the exhaust outlet on the
side of the unit is kept clear of any restriction.
Switch the SA
•
The lamp indicates the SA
3.3 Operating Environment
Operation of this equipment must be within the following ambient condition
Warning! Never operate a SAM suction unit in the presence of flammable gas such as
anaesthetic agents. This is an Explosion hazard!
3.4 Gauge (Manometer) - Indicated Vacuum
The unit has a gauge fitted to allow the vacuum to be set at a pre-determined level and monitored
during use. To achieve the desired degree of vacuum, occlude the tubing fitted to the patient inlet on
the collection container top, and read the indicated vacuum on the gauge. Adjust the vacuum control
until the required degree of vacuum is achieved. (Turning the knob clockwise
vacuum). The SA unit is now set to operate at the selected vacuum.
3.5 External Filter
Warning! Never operate a SA
The filter capsules are a sealed disposable bacterial or hydrophobic filter capsule. Both the bacterial
and hydrophobic filters have bacterial retention of 99.9999% ensuring safety and hygiene for patient
and operator. The 0.3 micron particle retention of the filter medium also gives not less than 99.985%
Dispersed Oil Particulate (D.O.P.) and so provides an effective barrier against possible aerosol
contamination. The hydrophobic filter also has an integrated micro porous membrane on the rear of
the filter medium which allows a clear flow of air through one way and an excellent block against any
accidental back flow the other. The external filters are fitted between the vacuum connector and the
filter capsule mount, and can be either a bacterial or hydrophobic filter. The connector, mount, and 'O'
Manual 117 Issue 15
SA 12, SA 14, SA 15 and SA 16 – UK
Operation and Maintenance Manual
3. INSTRUCTIONS FOR USE
unit please read the following instructions carefully.
unit is by removal of the mains power plug from the mains power supply.
unit on by pressing the green rocker switch so that it illuminates.
unit is operating and ready for use.
+40°C
-5°C
Temperature
suction unit without a MG Electric filter capsule.
unit from the mains power supply before
80%
%
30%
Humidity
unit.
increases the
