Summary of Contents for Mortuary Lift ULTIMATE 1000
- Page 1 Installation Suggestions...
- Page 2 MOUNTING OPTIONS You have several options when installing your ULTIMATE 1000™ LIFT. It can be mounted 1.) STATIONARY in a fixed location where the machine does not move or 2.) TRACK or All- ACCESS TRACK SYSTEM, where the lift can be moved from one location to another location.
- Page 3 1. Locate ceiling joists and pre-drill six 1/4” holes (depending on your joist spacing) for 3/8” lag screws approximately 2” deep on 16” centers. 2. Place 6 large eye lag bolts 6” outside the previously pre- drilled lag screw holes as shown. 3.
- Page 4 6. In securing the hoist to the ceiling it is very important to keep frame level and not to conform to the irregularities of the ceiling. Securing the Ultimate 1000 Lift A. Place lag screws in three corners and tighten until uniformly snug and firm.
- Page 5 Machine Base Circular Holes: • (4) Circular Holes • 9/16” Diameter • 2” from short edge of machine base Slotted Holes: • Used for Stationary mounting with Lag Bolts or All Thread • (10) Slotted holes – (5) on each side of the machine •...
- Page 6 Rev 4/5/2021 M ORTUARY LIFT. . . COMPANY THE ULTIMATE 1000 LIFT™ Cottage Grove Avenue S.E. Cedar Rapids, Iowa 52403 800-628-8809 • 319-364-4910 www.mortuarylift.com...
