- Page 1 Manual Operation & Maintenance Models ML-013P ML-014W...
-
Page 2: Remote Control
OPERATING INSTRUCTIONS TO OPERATE THE The lift is capable of raising and lowering deceased remains with GLIDETEC STRAPS and caskets with BLACK NYLON CASKET STRAPS. To raise remains or caskets, secure all use specific straps under the remains/casket and to the white nylon straps, press the “Raise”... - Page 3 GLIDETEC BODY STRAPS: 400 LBS. CAPACITY Yearly replacement recommended (see Strap placement (For bodies weighing over 400lbs use black nylon casket straps) DVD) These are the white plastic straps that are 36 inches length. They are to be used when lifting remains. Place one strap under the shoulder region, one under the buttock/ lower back region, and one under the knee region.
- Page 4 Start from either the left or reight side of the remains, take one end of the strap andpush it under the selected region of the body. Start form the head region and shimmy the strap down the length of the remains. This is the preferred technique in large cases.
- Page 5 For use with lifting caskets and cadavers weighing over 400 lbs. BLACK NYLON STRAPS: Yearly replacement recommended. These are the black nylon straps, which are 8 feet in length and have a metal “D” ring at each end. These are to be used when lifting a casket and remains over 400lbs..
- Page 6 HEAD SLING: This is the eye shaped fabric/plastic Yearly replacement recommended. piece which has nylon webbing sewn to it. The webbing can be adjusted to accommodate your needs. The hooks on the head sling are to be attached to the two rings that are attached to the two white nylon straps at the head end of the machine.
- Page 7 TRACK SYSTEMS: moves manually along the track. The machine can be pulled by any of the six white nylon straps. Simply hold the white nylon strap above the buckle and pull the remains/casket to the necessary position. Check ceiling attachments yearly. Tighten bolts as necessary.
- Page 8 New sheer pins have been provided. 5. All straps come from Mortuary lift Company rolled exactly the same way. If all straps are attached exactly the same way, all hooks and buckles will be facing inward so they don’t snag on casket interiors.
- Page 9 Machines Metal Base Pulley Wheels Secure the strap loop to the cotter pin on the pulley wheel Straps Hooks and strap roll should always face “INWARDS” 7. Place the new sheer pin through the grommet on the strap, the hole in the pulley wheel and the shafting. Then slide the new cotter pin through the side of the pulley wheel.
- Page 10 Convert Remote to Push Button Control For Model ML-014W IF THE REMOTE CONTROL FAILS TO STOP THE MACHINE FROM GOING UP AND DOWN, USE THE FOLLOWING PROCEDURE. Convert Wireless to Push Button 1. Unplug the Ultimate 1000 Lift 2. Locate the push button box on the side of the machine 3.
- Page 11 How to Changing the Frequency on Your Wireless Remote Control For Model: ML-014W WARNING Failure to read, understand or follow these procedures may result in damage to your machine, severe injury to yourself or others, or even death. You will need power to your machine to train your remote.
- Page 12 MODE_IND window indicating that the new signal is being initialized. 3. Once the button is released, the randomized address is saved and the LED light will begin flashing indicating that the Control Permission may now be set. 4. Press the CREATE_ADDR button with a paperclip again or wait 17 seconds for it to time out.
- Page 13 1. Never operate without the cover on the machine. REMINDERS 2. Never remove warning stickers from cover of the machine. 3. Check integrity of nylon lift straps before each use. 4. Check integrity of nylon lift strap hooks before each use. 5.
- Page 14 MORTUARY LIFT MODELS ML-013P ML-014W Mortuary Lift Company, Inc. (”MLC”) warrants this product against defects in materials or workmanship as follows: 1.) For a period of one year from the date of purchase by the original retail purchaser, MLC or an...
-
Page 15: Warranty Limitations
This limited warranty does not apply in the case of damage to the unit due to freezing, fire, flooding accident, misuse, abuse, alteration, improper handling and/or improper installation. In no event will Mortuary Lift Company be liable for incident or consequential damages from a defective unit or improper installation.
