DESCRIPTION

The High Energy Spark Igniter (HESI) is a Class 3 (special) igniter used for direct spark ignition of
oil or gas igniters or small burners. The 12 joules of power delivered to the spark tip easily ignites the
fuel. Three sparks per second are delivered. The High Energy Spark Igniter consists of three major
components: a power pack, a spark rod, and a cable.
The power pack is packaged in a NEMA-4 or NEMA-4X enclosure suitable for wall mounting at the
burner front. The power pack develops the 12 joules of power delivered to the spark tip through the
use of heavy-duty electrical components. It has a 100% duty cycle at temperatures up to 130° F
ambient.
The spark rod features a self-cleaning surface gap spark tip that is easily replaceable through a
threaded connection. Spark rods are available with an optional retraction assembly to allow the spark
tip to be inserted and retracted from the firing position.

FEATURES

Non-fouling Spark Tip
The surface gap spark tip produces a self-cleaning, highly reliable, 12-joule spark even in the presence
of moisture, oil, and carbon deposits.
Removable Spark Tip
The spark tip completely detaches from the spark rod through a threaded connection. Replacement of
the spark tip is quick and easy.
Safe Operation
Heavy-duty, UL-approved flexible cable connects the power unit to the spark rod assembly ensuring
operator safety.
Application Flexibly
Standard and retractable HESI models are available to fit a variety of igniter or burner types.
1
HIGH ENERGY SPARK IGNITER
December 15, 2020
FIREYE
SureFire
(HESI)
Instruction Manual
© 2020 Carrier
SF-1
®
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SureFire HESI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fireye SureFire HESI

  • Page 1: Description

    SF-1 December 15, 2020 FIREYE ® SureFire HIGH ENERGY SPARK IGNITER (HESI) Instruction Manual DESCRIPTION The High Energy Spark Igniter (HESI) is a Class 3 (special) igniter used for direct spark ignition of oil or gas igniters or small burners. The 12 joules of power delivered to the spark tip easily ignites the fuel.
  • Page 2: Table Of Contents

    Table of Contents DESCRIPTION ..................................1 FEATURES ................................... 1 SPECIFICATIONS................................3 OVERVIEW ..................................3 SAFETY ....................................7 INSTALLATION .................................. 7 COMMISSIONING ................................9 OPERATION ..................................10 TROUBLESHOOTING ..............................10 MAINTENANCE ................................10 RECOMMENDED SPARE PARTS ........................... 11 ORDERING INFORMATION: FIXED MOUNT HESI IGNITER ..................12 ORDERING INFORMATION: RETRACTABLE MOUNT HESI IGNITER ..............
  • Page 3: Specifications

    Ensure that cable connectors are facing downward. 2. Carefully insert the HESI spark rod tip into the guide tube until the spark rod extends into the primary ignition zone. With Fireye SureFire 20 gas igniters, position spark tip flush with front of baffle plate.
  • Page 4 HESI SPARK ROD The HESI spark rod comes in lengths from 14” (356mm) up to 180” (457 mm) in 2” (51mm) incre- ments. The HESI spark rod features a positioning rod and a removable surface gap spark plug tip designed for long life and ease of maintenance. High Energy Spark Rod Assembly FIGURE 1.
  • Page 5 HESI SPARK TIP The spark tip (provided with spark rod) comes in one of two lengths depending on the length of the spark rod. PART NUMBER SPARK TIP LENGTH 145-18 8” (203mm) for spark rods 36” (914mm) and shorter 145-19 27”...
  • Page 6 AUTOMATIC RETRACTION (optional) For automatic HESI retraction, you must specify the following: HESI Retractor Assembly (consisting of pneumatic cylinder, extended-position limit switch, packing gland and collar). Retraction mount tube (P/N MT1R-XXX). HESI spark rod (SFR-XXX). HESI Power Pack (P/N SF1-X). HESI interconnecting cable (P/N SF1-CA1-XX).
  • Page 7: Safety

    SAFETY Safety is the responsibility of each individual who installs, operates, or maintains Fireye equipment. The Fireye design of the HESI includes personnel safety as a basic design element. The HESI assembly uses a 2000-vdc energy source to produce a 12-joule spark for fuel ignition purposes.
  • Page 8 High Energy Power Pack. FIGURE 4. SPARK ROD In most applications, the HESI spark rod fits into a guide tube that houses the spark rod assembly. Observe the following steps for installing the spark rod assembly: Carefully insert the spark tip into the guide tube until the spark rod extends into the primary ignition zone.
  • Page 9: Commissioning

    LOCATION OF SPARK TIP IN OIL IGNITER FIGURE 6. SPARK TIP CABLE ASSEMBLY Connect power input leads to TB2, H (hot), N (neutral), and G (ground) to the power pack as shown in installation drawings and in Fig. 7. FIGURE 7. COMMISSIONING When you have completed the installation, perform a spark test and observe spark rod operation in the following manner.
  • Page 10: Operation

    Allow at least 2 minutes for the capacitor to discharge. Exercise extreme care when the power pack cover is open. MAINTENANCE Fireye recommends performing the following preventive maintenance every six SPARK TIP INSPECTION AND MAINTENANCE months.
  • Page 11: Recommended Spare Parts

    POWER PACK INSPECTION AND MAINTENANCE The following steps describe power pack inspection and maintenance. Disconnect all electric power from the power pack, and ensure that all residual voltage is dissi- pated. (See Safety section.) Open the power pack door. Test capacitor C1 for resistance across terminals 1 and 2. Test transformer T1 for resistance at the two red secondary leads.
  • Page 12: Ordering Information: Fixed Mount Hesi Igniter

    SELECT THE APPROPRIATE HESI POWER PACK PART NUMBER DESCRIPTION SF1-1 SureFire HESI Power Pack, 110 vac, NEMA 4 (painted steel) SF1-2 SureFire HESI Power Pack, 220 vac, NEMA 4 (painted steel) SF1-3 SureFire HESI Power Pack, 110 vac, NEMA 4X (stainless steel)
  • Page 13 High Energy Spark Igniter Spark Rod Length in inches (014 through 180) in 2” increments EXAMPLE: Specify a SureFire HESI Spark Rod - 72 inches long. Specify part number: SFR – 072 4. SELECT OPTIONAL HESI MOUNTING TUBE (Fixed) PART NUMBER DESCRIPTION MT1-006 Fixed Mount Tube 6”...
  • Page 14: Ordering Information: Retractable Mount Hesi Igniter

    SELECT THE APPROPRIATE HESI POWER PACK PART NUMBER DESCRIPTION SF1-1 SureFire HESI Power Pack, 110 vac, NEMA 4 (painted steel) SF1-2 SureFire HESI Power Pack, 220 vac, NEMA 4 (painted steel) SF1-3 SureFire HESI Power Pack, 110 vac, NEMA 4X (stainless steel)
  • Page 15 MT1R – XXX Retraction Mounting Tube Length in inches (028 through 170) in 2” increments EXAMPLE: Specify a Retraction Mounting Tube for a 72 inch long SureFire HESI Spark Rod (P/N SFR- 072). Specify part number: MT1R – 062 © 2020 Carrier...
  • Page 16 Fireye warranty, as stated in its General Terms and Conditions of Sale, pertains only to the Fireye products and not to any other equipment or to the combined system or its overall performance.
