Adax ET ECO SX.2 User Instructions

Thermostat user instructions

Explanation of programmes/modes/settings:

P1 – Lower temperature at night (night-time heating)
P2 – Programmes
Manual programme (works the same as when
starting the radiator for the first time – Step 1)
Step 1. Starting the radiator for the first time
Follow the steps below–
this process is used when you start the radiator for the first time,
and to reset the radiator after a power cut.
This calibrates and resets all settings.
1. Plug the radiator in to an electric outlet
2. Turn on the radiator
3. Adjust the control dial
(22°C) pointing towards the light
4. Press and hold the control dial in for 1 second untilthe light
blinks green
5. Press and hold the control dial in for 1 second untilthe light
blinks green
This process will reset all other settings; it is used when, for example, there has beena power cut or if you
want to cancel the night-time heatingprogramme.

Power cut

When a power cut occurs, the radiator will remember the settings (temperature) that were set
before the power cut occurred. It will start heating up again as soon as the power is on. If the temperature is changed,
the light will blink red–
To adjust the temperature, you must follow Step 1 "Starting the radiator for the first time".
If the radiator is turned off for a long period (e.g. during the summer), the light will blink red
again–follow the process for Step 1.

Child safety mode

The thermostat (control dial) can be locked to prevent children and others changing the radiator's settings and
Any knob movement will be indicated by
temperature.
Activate child safety mode
1. Turn the control dial to the desired temperature (e.g. 22°C)
2. Press and hold the control dial in for 3 seconds until the light blinks red
3. If you turn the dial at this point, the light will blink red. You cannot change the temperature
Turn off Child safety mode
1. Turn the control dial with the arrows (show the symbols) as when turning the radiator on
2. Press and hold the control dial in for 3 seconds until the light blinks green.
3. When the child safety mode is turned off, the radiator will heat at 22°C. Adjust to the desired temperature.
so 2 arrows face each other
indicating a power outage.
VP11
while mode or target temperature remains the same.
.
VPS10 Eco Basic
Hold 1 sec.
when it is turned on
.
.
