Adax WT User Manual

Thermostat layout
1 Display:
Set temperature value. It is represented in
•
integers and Celsius degrees.
2 Temperature indication light. Possible indications:
Is lighting when heater is on set temperature;
•
Is not lighting when heater's temperature is not
•
reached;
Blinking – when heater is connecting to the cloud.
•
3 WiFi indication light. Possible indications:
Permanently lighting, when electronic heater
•
device is connected to home net (router) and
cloud;
Not lighting – when heater isn't connected to
•
home network;
Blinking – when heater is connected to home
•
network but isn't connected to cloud.
4 Functions selection and confirmation button „OK". Used:
1. When heater is in direct mode:
By briefly clicking the button system is switching
•
from direct mode to editing mode;
2. When heater is in editing mode:
By briefly clicking the button a weekly heating
•
program is selected.
5 Button „+", possible values:
1. When heater is in direct mode and user is clicking
it temperature values are increasing by one
degree. Possible temperature interval is 5-35°C.
Max value is „35°C".
2. When heater is in editing mode and user is
clicking this button then program list is displayed
and user is navigating through it by going forward.
6 Button „-", possible values:
1. When heater is in direct mode and user is
clicking it temperature values are decreasing by
one degree. Possible temperature interval is 5-
35°C. Min value is „5°C".
2. When heater is in editing mode and user is
clicking this button then program list is displayed
and user is navigating through it by going
backwards.
WT
thermostat user manual
Display values
„20"
„HO"
„OF"
„--„
„AF"
„SC"
„rE"
Integer temperature value. Interval 5-35°C.
"Home" weekly program. By selecting it heating
temperature will be:
1. If heater is not connected to home
network it will keep 20°C. Until user using
„+" and „-" won't change it;
2. If heater is connected to home network it
will keep temperature by using „Home"
program.
"Office" weekly program. By selecting this mode,
heating will be:
1. If heater is not connected to home
network it won't be shown for user;
2. If heater is connected to home network,
heater will keep "Office", program
temperature.
The heater is in "stand-by" mode.
Antifrost weekly heating program. By selecting it,
heater will keep,,Antifrost temperature (by default
7°C).
„Smart config "indicating value, showing that user
started adding heater,to „Smart heater" app
(look,Heater's „Smart" configuration settings).
Factory reset indication value (look Factory data
reset).
EN
2016-09-20
art. no.: 62008
1
