Thermostat display description
1
The display shows the set temperature (° C) and the
abbreviated names of the optional heater features (see
"Display symbols").
2
Temperature indicator (red light). Available modes:
On - the heater is operating to reach the set
•
heating temperature.
Off - the set temperature has been reached.
•
Flashing - the heater is connecting to a cloud
•
computing service.
3
Wi-Fi indicator (blue light). Available modes:
On - the electric heating device is connected to
•
your home network (router) and a cloud
computing service.
Off - the heater is not connected to your home
•
network.
Flashing - the heater is connected to your home
•
network, but is not connected to a cloud
computing service.
4
Selection or confirmation button OK. Features:
1.
When the heater is operating in the Direct Control
mode, briefly press the key to switch from the
Direct Control mode to the Edit mode.
2.
When the heater is operating in the Edit mode,
briefly press the key to select the desired weekly
heating programme.
5
"+" button. Available values:
1.
When the heater is in the Direct Control mode,
press this button to increase the numerical value
of the set temperature by 1 °C. The temperature
may be set within the 5–35 °C range. The largest
value shown on the display is 35.
2.
When the heater is operating in the Edit mode,
press this button to move forward in the
programme list.
6
"-" button. Available values:
1.
When the heater is in the Direct Control mode,
press this button to decrease the numerical value
of the set temperature by 1 °C. The temperature
may be set within the 5-35 °C range.
2.
When the heater is operating in the Edit mode,
press this button to move back in the programme
list.
WT
thermostat user manual
Introduction
This manual is to acquaint the user with the electric heater system, its
functioning, use and capabilities.
The Smart Heater app is designed to manage the existing electric heating
devices according to the user's current location directly from a mobile device.
This device is not suitable for use by persons (including children) with
physical, sensory or mental disabilities, or those who lack experience and
knowledge, except in cases where these persons are supervised or they were
given instruction on how to use the device.
Children should be supervised to ensure that they do not play with the
appliance.
Turning on the heater
The electric heating device is activated by pressing the On/Off button on the
side of the electric heating device.
Note: the first time you turn on the electric heating device, the display shows
20 ° C. The heater starts to operate as soon as it is switched on.
Turning off the heater
The electric heating device is deactivated by pressing the On/Off button on
the side of the electric heating device.
Note: after the heater is switched off completely or upon power cut-off, the
settings will be saved for 24 hours.
Turning off the heating
The heating can be turned off by using the following commands:
1.
By pressing and holding the button "-" in the Direct Control mode
until the temperature value on the display changes to "--". This
means that the heater has been set to standby mode.
2.
By pressing the buttons "+" or "-" in the Edit mode to select the
value "--" from the menu list and briefly pressing the OK button,
the heater is set to standby mode (it is still on, but will not heat).
Turning on the heating
The heating can be turned on by using the following commands:
1.
Pressing the OK button on the display opens the menu, where you
can select a preferred heating mode.
2.
By pressing the "+" button on the display, you can set a preferred
temperature.
www.adax.no
14/09/2016
art. no.: 62008
EN
