I-Motioncaddys im4 Range 2013 Manual page 5

Technical Specifications
Body & Chassis
• Front and rear headlights
• Front and rear indicator lights
• Steel frame construction
• Strong fibreglass body
• Rust protected powder coated steel work
• Easy battery access
• Range of colours available
Power
• Motor 36V 1200 watt permanent magnetism
• Sealed lead acid batteries 12V 75AH
• Automatic pulse charger Input AC110V/240V
• Optional Output DC36V/5A/8A
• Speed switch High (12km/h) Low (6.4km/h)
• Recharge time 6-8 hours
• Maximum travel distance 50km
• Curtis Controller 1227-3402 DC36V/160A
• Curtis Connector
• Micro switch fitted
• Emergency foot brake
• Hall accelerator continuous variable speed system.
Performance
• One person seating capacity
• Carrying capacity 200kg
• Weight 153kg with batteries, 100kg without batteries
• Maximum speed 12km/h
• Slope climbing capacity 17 degrees
• Brake range ≤4m
• Turning radius ≤3m
• Forward & reverse console mounted
Dimensions
Length 49.5" (127.7cm) Width 32.5" (82.6cm) Height 42" (106.7cm)
Height folded 31" (78.7cm) with quick seat release 27" (68.6cm)
Minimal ground clearance 4.5" (11cm)
Other
Features
• Helix spring absorbers
• Tyres: 32.5cm x 15cm
• Japanese wheel
bearings
• Electromagnetic &
mechanical braking
system
• Full range of optional
accessories available
