WEBTEC 1 Series User Manual page 9

EU Specification
Flow
Model
Range
Number
(lpm)
HT302-B-6 8 - 300
HT402-B-6 10 - 400
HT602-S-7 20 - 600
HT802-S-7 20 - 800
Dimensions (Millimetres)
HT302/402: 240 Wide, 200 Deep, 200 High
Weight: Unpacked 6.5 kg, Shipped 7 kg (Approx.)
US Specification
Flow
Model
Range
Number
(gpm)
HT302-S-6 4 - 80
HT402-S-6 4 - 100
HT602-F-3 6 - 160
HT602-S-7 6 - 160
HT802-F-3 7 - 200
HT802-S-7 7 - 200
Dimensions (Inch)
HT302/402: 9.45" W, 7.87" D, 7.87" H
Weight: Unpacked 14.33 lb
Shipped approximately 15.4 lb
Connections
By flexible hoses 1 - 2 meter minimum length (3 - 6 foot). Care should be taken to avoid constrictions
at the inlet or outlet port.
Adaptors
Adaptor Fitting and flanges are available to suit the range of flow blocks. Consult the sales office.
Flow
Measured by the electronic count of an axial turbine designed to minimise the effects of variation in
temperature and viscosity. The large analogue readout meter has high / low scales selected by a switch.
Accuracy: ± 1% of full scale.
Pressure
Glycerine filled dual scale pressure gauge 420 bar / 6000 psi (7000 psi / 480 bar for HT602/802)
connected by capillary tube to a shuttle valve built into the flow block thereby always indicating the
high pressure side of the valve regardless of flow direction.
Accuracy: ± 1.6% of full scale.
Temperature
Sensed by a thermistor pick-up in the oil flow for fast response. Temperature is displayed in °C/°F.
Accuracy: ± 2°C, 4°F.
Speed
Rotational speed of motors, shafts etc., can be measured by optional infra-red phototachometer
using one or more retro-reflective marks. Range: See Table.
Accuracy: ± 2% of full scale.
Seals
Viton seals compatible with oil, water/oil emulsion are fitted as standard. EP seals for phosphate-
ester are available to special order.
Specification
Flow Scales Pressure Temperature
(lpm) Range
Low High (bar)
0 - 75 0 - 300 0 - 420
0 - 100 0 - 400 0 - 420
0 - 150 0 - 600 0 - 480
0 - 200 0 - 800 0 - 480
Flow Scales Pressure Temperature
(gpm) Range
Low High (psi)
0 - 20 0 - 80 6000
0 - 25 0 - 100 6000
0 - 40 0 - 160 3000*
0 - 40 0 - 160 7000
0 - 50 0 - 200 3000*
0 - 50 0 - 200 7000
* per J508 SAE C61 standard
Speed
Range
(rpm)
(°C)
10 - 120 300 - 3000
10 - 120 300 - 4000
10 - 120 300 - 6000
10 - 120 300 - 5000
HT602/802: 245 Wide, 225 Deep, 225 High
Weight: Unpacked 10 kg, Shipped 11 kg (Approx.)
Speed
Range
(rpm)
(°F)
32 - 250 300 - 3000 1-5/16"-12 UN #16 ORB
32 - 250 300 - 4000 1-5/16"-12 UN #16 ORB
32 - 250 300 - 6000 1.5" C61 4-Bolt Flange
32 - 250 300 - 6000 1-7/8"-12 UN #24 ORB
32 - 250 300 - 5000 1.5" C61 4-Bolt Flange
32 - 250 300 - 5000 1-7/8"-12 UN #24 ORB
HT602/802: 9.65" W, 8.86" D, 8.86" H
Weight: Unpacked 22 lb
Shipped approximately 24.2 lb
8
Inlet/Outlet
Ports
1" BSPF
1" BSPF
1-7/8" -12 UN
1-7/8" -12 UN
Inlet/Outlet
Ports
