WEBTEC 1 Series User Manual page 11

EU Specification
Model Flow Range
Number (lpm)
DHT302-B-6 8 - 300
DHT402-B-6 10 - 400
DHT602-F-3 20 - 600
DHT602-S-7 20 - 600
DHT802-F-3 20 - 800
DHT802-S-7 20 - 800
Dimensions (Millimetres)
DHT302/402: 240 Wide, 200 Deep, 200 High
Weight: Unpacked 6.5 kg, Shipped 7 kg (Approx.)
US Specification
Model Flow Range
Number (gpm)
DHT302-S-6 4 - 80
DHT402-S-6 4 - 100
DHT602-F-3 6 - 160
DHT602-S-7 6 - 160
DHT802-F-3 7 - 210
DHT802-S-7 7 - 210
Dimensions (Inch)
DHT302/402: 9.45" W, 7.87" D, 7.87" H
Weight: Unpacked 14.33 lb
Shipped approximately 15.4 lb
Connections
Flow block connection by flexible hoses 1 - 2 metres (3 - 6ft) long.
Adaptors
Adaptor Fitting kits and flanges are available to suit the range of flow blocks. Consult the sales office.
Flow
Measured by the electronic count of an axial turbine. The large digital display reads in lpm, UK gpm
or US gpm, selected by push button and indicated by a cursor arrow on the display.
Accuracy: ± 1% of indicated reading (over 15 - 100% of range).
Pressure
Glycerine filled dual scale pressure gauge bar / psi connected by capillary tube to a shuttle valve
built into the flow block thereby always indicating the high pressure side of the valve regardless of
flow direction.
Accuracy: ±1.6% of full scale.
Temperature
Sensed by a thermistor pick-up in the oil flow for fast response. Temperature is displayed in °C or °F
for either the internal or external flow block.
Accuracy: ± 1°C, 2°F.
Speed
Rotational speed of motor shafts etc., can be measured by optional infra-red phototachometer using
one or more reflective marks. Range 300 - 6000 rpm.
Accuracy: ± 1/4% of full scale with one count per revolution.
Seals
Viton seals compatible with oil, water/oil emulsion are fitted as standard. EP seals for phosphate-
ester are available to special order.
Specification
Pressure Temperature
Range (bar) Range (°C)
0 - 420 10 - 120
0 - 420 10 - 120
0 - 210 10 - 120
0 - 480 10 - 120
0 - 210 10 - 120
0 - 480 10 - 120
DHT602/802: 245 Wide, 225 Deep, 225 High
Weight: Unpacked 10 kg, Shipped 11 kg (Approx.)
Pressure Temperature
Range (psi) Range (°F)
6000 32 - 250
6000 32 - 250
3000* 32 - 250
7000 32 - 250
3000* 32 - 250
7000 32 - 250
* per J508 SAE C61 standard
DHT602/802: 9.65" W, 8.86" D, 8.86" H
Weight: Unpacked 22 lb
10
Speed Inlet/Outlet
(rpm) Ports
300 - 6000 1" BSPF
300 - 6000 1" BSPF
300 - 6000 Code 61 - 1 1/2" 4-bolt Flange
300 - 6000 1 7/8" - 12 UN
300 - 6000 Code 61 - 1 1/2" 4-bolt Flange
300 - 6000 1 7/8" - 12 UN
Speed Inlet/Outlet
(rpm) Ports
300 - 6000 1-5/16"-12UN #16 O-ring
300 - 6000 1-5/16"-12UN #16 O-ring
300 - 6000 1-1/2" C61 4-Bolt Flange
300 - 6000 1 7/8"-12UN #24 O-ring
300 - 6000 1-1/2" C61 4-Bolt Flange
300 - 6000 1 7/8"-12UN #24 O-ring
Shipped approximately 24.2 lb
