Specification - WEBTEC 1 Series User Manual

EU Specification
Model Flow Range
Number (lpm)
DHT401-B-6 10 - 400
DHT801-S-7 20 - 800
Dimensions (Millimetres)
DHT401: 240 Wide, 200 Deep, 200 High
Weight: Unpacked 6.5 kg, Shipped 7 kg (Approx.)
US Specification
Model Flow Range
Number (gpm)
DHT401-S-6 4 - 100
DHT801-S-7 7 - 210
DHT801-F-3 7 - 210
Dimensions (Inch)
DHT401: 9.45" W, 7.87" D, 7.87" H
Weight: Unpacked 14.33 lb
Shipped approximately 15.4 lb
Connections
Flow block connection by flexible hoses 1 - 2 metres (3 - 6ft) long.
Adaptors
Adaptor Fitting kits and flanges are available to suit the range of flow blocks. Consult the sales office.
Flow
Measured by the electronic count of an axial turbine designed to minimise the effects of variation in
temperature and viscosity. The EU version displays flow in lpm, the US version displays flow in gpm.
Accuracy: ± 1% of full scale.
Pressure
Glycerine filled dual scale pressure gauge bar / psi connected by capillary tube to a shuttle valve
built into the flow block thereby always indicating the high pressure side of the valve regardless of
flow direction.
Accuracy: ± 1.6 % of full scale.
Temperature
Sensed by a thermistor pick-up in the oil flow for fast response. Temperature is permanently
displayed in °C/°F.
Accuracy: ± 1°C, 2°F.
Seals
Viton seals compatible with oil, water/oil emulsion are fitted as standard. EP seals for phosphate-
ester are available to special order.

Specification

Pressure Range Temperature
(bar) Range (°C)
0 - 420
0 - 480
DHT801: 245 Wide, 225 Deep, 225 High
Weight: Unpacked 10 kg, Shipped 11 kg (Approx.)
Pressure Range Temperature
(psi) Range (°F)
6000 32 - 250
7000 32 - 250
3000* 32 - 250
* per J508 SAE C61 standard
DHT801: 9.65" W, 8.86" D, 8.86" H
Weight: Unpacked 22 lb
6
Inlet/Outlet
Ports
0 - 120 1" BSPF
0 - 120 1 7/8" - 12 UN
Inlet/Outlet
Ports
1-5/16" - 12 UN #16 O-ring
1-7/8" - 12 UN #24 O-ring
1.5" C61 4-Bolt Flange
Shipped approximately 24.2 lb
