Daewoo Cyclone Freedom FLR00010 User Manual page 10

2. If the Aluminium Tube (17) is not required, attach the Crevice Tool &
Upholstery Tool (14) directly to the cleaner, this useful for cleaning soft
furnishings, car seats, stairs, etc.:
2
Emptying and Cleaning Your Cordless Vacuum Cleaner
WARNING! Always disconnect the cleaner from the mains charger before
cleaning.
1
WARNING! DO NOT continue to use your vacuum cleaner above the
Maximum Fill level shown arrowed above as permanent damage may occur to the
appliance.
2. To empty the cleaner, hold the Dust
Compartment (4) over a dust bin and press
the Dust Release Catch (3) (arrowed right)
and the base of the dust compartment will
swing open and allow the collected dust to
fall out into the dust bin.
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cyclone Freedom 22.2V Cordless Vacuum
1. Once the Dust compartment (4)
fills to the level shown arrowed
left, it will need emptying and the
filters cleaned.
2
Cleaner
FLR00010
User Manual
10
