STI Stopper Station SS-2008 Series Manual

Push button pneumatic timer button
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Stopper
Push Button Pneumatic Timer Button
Pneumatic Timer Models
SS-2008
SS-2108
SS-2208
SS-2308
SS-2408
We protect the things that protect you. ®
®
Station Series SS-2008
Red
Green
Yellow
White
Blue
ADA
for operation
ALL MODELS COME WITH A
COLOR MATCHED SURFACE
MOUNT BACKBOX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stopper Station SS-2008 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STI Stopper Station SS-2008 Series

Summary of Contents for STI Stopper Station SS-2008 Series

  • Page 1 ® Stopper Station Series SS-2008 Push Button Pneumatic Timer Button for operation Pneumatic Timer Models SS-2008 ALL MODELS COME WITH A SS-2108 Green COLOR MATCHED SURFACE SS-2208 Yellow MOUNT BACKBOX SS-2308 White SS-2408 Blue We protect the things that protect you. ®...
  • Page 2 - 2 -...
  • Page 4 PRODUCT DIMENSIONS 1.62 in. 1.58 in. (41mm) (40mm) 3.25 in. (82mm) 4.87 in. (124mm) PUSH 1.375 in. (35mm) VIEW SHOWING FRONT HOUSING REMOVAL BUTTON AND SWITCH ASSEMBLY 10271 SWITCH HOUSING RED, GREEN, YELLOW, 19011 SCREW ALLEN HEAD WHITE AND BLUE #8 - 32 x 3/8 (1) PROVIDED 19015 WRENCH (1) PROVIDED...
  • Page 5 BACKBOX PREPARATION (NOT INCLUDED WITH FLUSH MOUNT COVERS) DRILL POINT LOCATIONS PROVIDED DRILL POINT L DRILL POINT L TIONS PR VIDED TOP AND BOTTOM FOR 1/2 in. OP AND B OP AND B OR 1/2 in. CONDUIT FITTINGS. ONDUIT FIT ONDUIT FIT TINGS DRILL AS NEEDED...
  • Page 6 CONTACT DIAGRAM NC (GREEN) (BLACK) NC NO (WHITE) (RED) NO LEAD WIRE COLORS IN PARENTHESIS. CONTACTS One set NO and one set NC COUNTERCLOCKWISE SWITCH INFORMATION CLOCKWISE TIMER RANGE ADJUSTMENT SCREW ADJUSTMENT RANGE - 2 TO 60 SECONDS TIMER FACTORY SET TO MINIMUM TIME SETTING.
  • Page 7 INSTALLATION WITH PROVIDED SURFACE BACKBOX 19018 ANCHOR 19018 ANCHOR 19018 ANCHOR (4) PROVIDED (4) PR (4) PR VIDED 71100A-COLOR SURFACE BOX 71100A OR SURF CE B DRILL (4) 3/16 in. DRILL (4) 3/16 in. 19039 SCREW #6 x 1-1/4 in. 19039 SCREW #6 x 1 1/4 in.
  • Page 8 Three year guarantee against breakage of polycarbonate in normal use (one year on electro mechanical and electronic components). Electronic warranty form at www.sti-usa.com/wc14. 2306 Airport Rd • Waterford, MI 48327 Phone: 248-673-9898 • Fax: 248-673-1246 800-888-4STI (4784) • sti-usa www.
