Programming a Directory Record with a PIN into a TEC1A

The following steps show how to set a directory record (Code, Name, Phone # and PIN
for entrance 1 with 24/7 access) using the keypad. It assumes the TEC1A is powered on
and that the Welcome Page e.g. "Press # to View Directory" is displayed before starting.
Note that Steps 4 and 5 are included to check if PINs are enabled. Once PINs are enabled,
steps 4 and 5 can be skipped for future entries. For all other settings please refer to
"TEC1A Series Menus".
Steps to Program a Directory Record with a PIN into a TEC1A using the Keypad
# Step Description
1 Enter Programming
Mode
2 Enter Password
3 Select Codes & Names
4 Skip this step if you know
PINs are enabled
5 Complete check of
Enable PINs setting
6 Select Add New
7 Enter a code e.g. 100
8 Enter a name e.g. JOHN.
9 Enter phone number
10 Enter 4-digit PIN
11 Set Entrance 1
12 Set Group 0 (24/7 access) Press 0 then *
13 Enter more records
OR
14 Exit Programming Mode
Rev B2
TEC1A Installer Guide
Keypad Action
Press * and 0 at same time
Press 6 digit password (default is
"777777") then *
Press 1
Press 8
If ENABLE PINS = 0, press 1 then *
If ENABLE PINS = 1, press *
Press 1
Press "100" then *
Note: # moves cursor to next
character
Press J# O# H# N# then *
e.g. 3055551212 then *
e.g. 1234 then *
Press 1 then *
Repeat as needed from end of step 6
with new data.
Note that no two codes and no two
pins can be identical.
Press *0 together
Page 11 of 11
01/20
Resulting Display
PASSWORD
MAIN MENU 1 - 8
CODES & NAMES
SELECT 1 - 9
ENABLE PINS = 0 or
ENABLE PINS = 1
CODES & NAMES
SELECT 1 - 9
CODE =
NAME =
PHONE # =
PIN =
ENTRANCE = 0
TG GROUP = 0
CODE =
Welcome Page
