61164 NPT CONNECTION / RACCORDEMENT
• 1/2" male water inlets - NPT/sweat / Entrées d'eau 1/2" mâle - NPT/soudé
• 1/2" male water outlets - NPT/sweat / Sorties d'eau 1/2" mâle - NPT/soudé
61166 PEX CONNECTION / RACCORDEMENT
• PEX water inlets and top outlet / Entrées d'eau et sortie d'eau du haut PEX
• 1/2" male bottom water-outlet - NPT/sweat / Sortie d'eau du bas 1/2" mâle - NPT/soudé
61168 WB CONNECTION / RACCORDEMENT
• WB water inlets and top outlet / Sortie d'eau du bas 1/2" mâle - NPT/soudé
• 1/2" male bottom water-outlet - NPT/sweat / Sortie d'eau du bas 1/2" mâle - NPT/soudé
Pressure balance with diverter
61164 / 61166 / 61168
NPT/sweat / Pex / WB connections with diverter
Raccordements NPT/sweat / Pex / WB avec déviateur
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ALT Aquabrass 61164
Summary of Contents for ALT Aquabrass 61164
- Page 1 Pressure balance with diverter 61164 / 61166 / 61168 NPT/sweat / Pex / WB connections with diverter Raccordements NPT/sweat / Pex / WB avec déviateur 61164 NPT CONNECTION / RACCORDEMENT • 1/2" male water inlets - NPT/sweat / Entrées d’eau 1/2" mâle - NPT/soudé •...
- Page 2 Félicitations pour l’achat de purchase of your product votre produit By purchasing an Aquabrass / Alt product, you are En achetant un produit Aquabrass / Alt, vous prenez taking part in the global movement for better living. We part au mouvement global pour le mieux-vivre. Nous take pride in manufacturing drinking water faucets that sommes fiers de fabriquer des robinets d’eau potable...
- Page 3 BEFORE YOU START AVANT DE COMMENCER INSTALLATION How to Use the Plastic Protector Cap CAUTION: FOR BEST RESULTS, WE STRONGLY MISE EN GARDE: POUR OBTENIR UN RÉSULTAT The valve is covered by a plastic protector cap. It can be used as a RECOMMEND THE INSTALLATION OF THIS VALVE BE OPTIMAL, NOUS RECOMMANDONS FORTEMENT QUE template for setting the depth of the valve in the wall.
- Page 4 INSTALLATION Installing the valve Installing the cartridge Unscrew the cartridge holder (1) and remove the protective plug. Once the mixer location is determined, position Insert the cartridge (2) into the valve body as shown (Fig.4). the valve in between 2x4 studs inside the wall on a Min [43.00] 1 11/16”...
- Page 5 INSTALLATION MAINTENANCE Connecting the Water To Service The Cartridge Shut off the main water supply, then remove all the Connect the hot and cold water inlets and the mixed components from (1) to (8). Fig.6. Afterwards, shut off water outlets (Fig.5). The hot water must always be the 2 check valves (11) by turning them clockwise with connected on the left side and the cold water on the a screwdriver.
- Page 6 Products that are deemed defective must be returned to our factory for inspection prior to replacement. To clean your Aquabrass / Alt faucet or accessory, wash with a wet nonabrasive soapy cloth. Then wipe dry with a soft towel or cloth.
- Page 7 Project Divison Projet Last revision: 05/09/2018...
