22 hp electric start 42" mower. automatic transmission lawn tractor
Hide thumbs

Advertisement

Table of Contents

REPAIR
PARTS
MANUAL
MODEL NO.
944.101060
IMPORTANT:
Read and fol low
all Safety Rules
and In struc tions
Be fore Op er at ing
This Equip ment
* The power rating as declared by the engine manufacturer is the average gross power output at the specified RPM of a typical production engine for the engine model mea-
sured using SAE Standards for engine gross power. Please refer to the engine manufacturer for details.
115816924 Rev. 6
22 HP
ELECTRIC START
42" MOWER
AUTOMATIC TRANSMISSION
LAWN TRACTOR
Sears Canada, Inc., Toronto, Ontario M5B 2B8
*
03.22.18 JSE
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 944.101060 2018 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftsman 944.101060 2018

Summary of Contents for Craftsman 944.101060 2018

  • Page 1 REPAIR PARTS MANUAL MODEL NO. 944.101060 IMPORTANT: Read and fol low all Safety Rules and In struc tions Be fore Op er at ing This Equip ment 22 HP ELECTRIC START 42" MOWER AUTOMATIC TRANSMISSION LAWN TRACTOR * The power rating as declared by the engine manufacturer is the average gross power output at the specified RPM of a typical production engine for the engine model mea- sured using SAE Standards for engine gross power.

  • Page 2: Table Of Contents

    HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them.

  • Page 3: Schematic

    TRACTOR - - MODEL NUMBER 944.101060 SCHEMATIC SCH12 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) ELECTRIC CLUTCH WHITE PTO SWITCH WHITE BLACK (DISENGAGED) WHITE BLACK GRAY CLUTCH/BRAKE (PEDAL UP) REVERSE SWITCH (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK...

  • Page 4: Electrical

    TRACTOR - - MODEL NUMBER 944.101060 ELECTRICAL T11S 12V Outlet (If Equipped) Charge Indicator (If Equipped) Service Minder(If Equipped)
  • Page 5 TRACTOR - - MODEL NUMBER 944.101060 ELECTRICAL KEY PART NO. NO. DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 587205101 Box Battery 176138 Switch Interlock Push-In 400252 Harness Socket Light w/4152J 4152J Bulb Light 585555601 Cable Btry. 585555501 Cable Starter 175158...

  • Page 6: Chassis

    TRACTOR - - MODEL NUMBER 944.101060 CHASSIS chassis-tex_TALON II_1...
  • Page 7 TRACTOR - - MODEL NUMBER 944.101060 CHASSIS KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 580485906 Dash 183 74520520 Bolt 5/16-18 x 1-1/4 580354407 Hood 189 17000512 Screw 5/16-18 x 3/4 580485601 Lens LH 191 580485101 Mylar Headlight/Reflective Lens RH 580485302 Grille 194 73900500...

  • Page 8: Drive

    TRACTOR - - MODEL NUMBER 944.101060 DRIVE drive-tex_K46_pedal_158_r1...
  • Page 9 TRACTOR - - MODEL NUMBER 944.101060 DRIVE KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION – – – – – Transaxle, Tufftorq K46BT (426120) 183 137057 Spacer Split (See Transaxle Breakdown.) 184 196439X428 Handle Parking Brake 123583X 185 72110622 Bolt Rdhd Sqnk 3/8-16 x 2-1/2 19131316 Washer 13/32 x 13/16 x 16 Ga.

  • Page 10: Engine

    TRACTOR - - MODEL NUMBER 944.101060 ENGINE SPARK ARRESTER KIT engine-tex_bs-2cyl_155...
  • Page 11 TRACTOR - - MODEL NUMBER 944.101060 ENGINE KEY PART NO. NO. DESCRIPTION Engine B&S Model No. 44R677-0026-G1 – – – – – (586607601)(See Engine Breakdown.) 589818701 Muffler 501832601 Keeper Belt Engine 587241501 Clutch Electric 405097 Pulley Engine 532438025 Tank Fuel 585124802 Cap Fuel 421473X428...
  • Page 12 TRACTOR - - MODEL NUMBER 944.101060 STEERING ASSEMBLY steering-tex_TTR_73...

  • Page 13: Steering

    TRACTOR - - MODEL NUMBER 944.101060 STEERING ASSEMBLY KEY PART NO. NO. DESCRIPTION 414803X428 Wheel, Steering 436870 Axle Asm., Front 436873 Spindle Asm., LH 436874 Spindle Asm., RH 6266H Washer Thrust 0.75 x 1.23 121748X Washer 25/32 x 1-5/8 x 16 Ga. 12000029 Ring, Klip #T5304-75 184946X667...

  • Page 14: Mower Deck

    TRACTOR - - MODEL NUMBER 944.101060 MOWER DECK 42_D_elec-Tex_25_r4...
  • Page 15 TRACTOR - - MODEL NUMBER 944.101060 MOWER DECK PART DESCRIPTION 196495X613 Mower Housing 72140506 Bolt RDHD.SQNK. 5/16-18 unc x 3/4 195186 Arm Suspension 424752 Blade, 3N1 422719 Blade 134149 Blade 139775 Blade 138971 Blade 584309301 Screw 587256501 Shaft Assembly, Mandrel 187281 Housing, Mandrel 585323901...

  • Page 16: Mower Lift

    TRACTOR - - MODEL NUMBER 944.101060 MOWER LIFT 101* lift-tex_42 *Key 91 may be substituted for Key 101 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 422027 Shaft Asm., Lift 17000612 Screw 3/8-16 x .75 426896 Lever Asm., Lift RH 195270 Link Lift Susp.

  • Page 17: Seat

    TRACTOR - - MODEL NUMBER 944.101060 SEAT ASSEMBLY seat-tex_6.5SL_11 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 586507601 Seat 197661 Handle Slide Seat 180166 Bracket Pivot Fender 198200 Spring Latch Seat 73800600 Nut, Lock W/Ins. 3/8-16 unc 74760612 Bolt 3/8-16 x 3/4 587613301 Spring, Seat Cprsn...

  • Page 18: Decals

    TRACTOR - - MODEL NUMBER 944.101060 DECALS KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 581894601 Decal, Steering 581580001 Decal, Mower V-Belt SCH. 585767601 Decal, Hood 586207901 Decal, Sideskirt RH 584904601 Decal, Deck/Deflect Warning 586207902 Decal, Sideskirt LH 582522401 Decal, Engine HP 193226X428...

  • Page 19: Engine Breakdown

    TRACTOR - - MODEL NUMBER 944.101060 BRIGGS ENGINE - MODEL NUMBER 44R677, TYPE NUMBER 0026-G1 1036 1058 1329 1330 1123 1124 633A 1124A 276B 1353 276A 1095 943A 1022 1022 118A 1012 306A 307A 668A 1005 1070...
  • Page 20 TRACTOR - - MODEL NUMBER 944.101060 BRIGGS ENGINE - MODEL NUMBER 44R677, TYPE NUMBER 0026-G1 1169 186A 186B 918A 1128 305A 1124A 1126 305B 117A 1124 1040 186B 1127 1051 1059 1090 1119...
  • Page 21 TRACTOR - - MODEL NUMBER 944.101060 BRIGGS ENGINE - MODEL NUMBER 44R677, TYPE NUMBER 0026-G1 1023 1027 1022 1023A 1022 1022 1029 1029A 1100 1017 1013 1022 1029 1029A 1100 552A 1024 1026 1026A...
  • Page 22 TRACTOR - - MODEL NUMBER 944.101060 BRIGGS ENGINE - MODEL NUMBER 44R677, TYPE NUMBER 0026-G1 PART PART DESCRIPTION DESCRIPTION 591695 Cylinder Assembly 699724 Float-Carburetor 797673 Bushing/Seal Kit (Magneto Side) 699729 Tube-Fuel Transfer 391086s Seal-Oil (Magneto Side) 690994 Gasket-Float Bowl 796307 Sump-Engine 796228 Kit-Choke Shaft...
  • Page 23 TRACTOR - - MODEL NUMBER 944.101060 BRIGGS ENGINE - MODEL NUMBER 44R677, TYPE NUMBER 0026-G1 PART PART DESCRIPTION DESCRIPTION 794903 Plug 797408 Hose-Vacuum (Rocker Cover #1) 795912 Plate-Carburetor 918A 799160 Hose-Vacuum (EVAP) 591661 Elbow-Intake 695239 Screw (Choke Control Bracket) 593240 Filter-Air Cleaner Cartridge 796222 Seal-O Ring (Oil Pump Cover)

  • Page 24: Transaxle Breakdown

    TRACTOR - - MODEL NUMBER 944.101060 TUFF TORQ TRANSAXLE - MODEL NUMBER K46BT MODEL K46BT 7A646084180 ACTUAL PARTS MAY NOT APPEAR AS SHOWN...
  • Page 25 TRACTOR - - MODEL NUMBER 944.101060 TUFF TORQ TRANSAXLE - MODEL NUMBER K46BT PART DESCRIPTION – – – – – – – K46BT TRANSAXLE 414395 VENT VALVE 15 414396 MAGNET 414397 MAGNET HOLDER 415923 PUMP SHAFT/BEARING KIT 414398 BYPASS LEVER 414399 SEALING CAP 30 414400...
