Owner's Manual
ROTARY LAWN MOWER
6.75 Horsepower
21" Multi-Cut
Model No.
944.365470
CAUTION:
Read and follow all
Safety Rules and In struc tions
before operating this equipment
Sears Canada, Inc., Toronto, Ontario M5B 2B8

Advertisement

Table of Contents
loading

Related Manuals for Craftsman 944.365470

Summary of Contents for Craftsman 944.365470

  • Page 1 Owner’s Manual ROTARY LAWN MOWER 6.75 Horsepower 21" Multi-Cut Model No. 944.365470 CAUTION: Read and follow all Safety Rules and In struc tions before operating this equipment Sears Canada, Inc., Toronto, Ontario M5B 2B8...

  • Page 2: Table Of Contents

    Warranty service is available by returning the Craftsman Power Mower to the nearest Sears Service Centre/Department in Canada. This warranty applies only while this prod- uct is used in Canada.
  • Page 3 • Do not pull mower backwards unless • Do not trim excessively steep slopes. absolutely nec es sary. Always look down • Do not mow on wet grass. Reduced and behind before and while moving footing could cause slipping. backwards. •...

  • Page 4: Product Specifications

    V. GENERAL SERVICE • Never attempt to make wheel height • Never run machine inside a closed area. adjustments while the engine is running. • Never make adjustments or repairs with • Grass catcher components are sub ject the engine (motor) running. Dis con nect the to wear, dam age, and de te ri o ra tion, spark plug wire, and keep the wire away from the plug to prevent ac ci den tal starting.

  • Page 5: Assembly/Pre-Operation

    ASSEMBLY / PRE-OPERATION Read these instructions and this manual in Operator MOWING its entirety before you attempt to assemble presence POSITION or operate your new lawn mower. control bar IMPORTANT: This lawn mower is shipped LIFT WITHOUT OIL OR GASOLINE in the engine.

  • Page 6: Operation

    OPERATION KNOW YOUR LAWN MOWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. These symbols may appear on your lawn mower or in literature supplied with the product.
  • Page 7 REAR BAGGING The operation of any lawn • Lift rear door of the lawn mower and mower can result in foreign place the grass catcher frame hooks objects thrown into the onto the door pivot pins. eyes, which can result in •...
  • Page 8 BEFORE STARTING ENGINE ADD OIL Your lawnmower is shipped without oil in the engine. For type and grade of oil to use, see “EN GINE” in the Maintenance section of this manual. CAUTION: DO NOT overfi ll engine with oil, or it will smoke heavily from the muffl er on startup.
  • Page 9 • Pores in cloth grass catchers can be- Gasoline come fi lled with dirt and dust with use fi ller cap and catchers will collect less grass. To prevent this, reg u lar ly hose catcher off with water and let dry before using. •...

  • Page 10: Maintenance Schedule

    MAINTENANCE BEFORE AFTER EVERY EVERY EVERY BEFORE EACH EACH 25 HOURS STORAGE HOURS OR SEASON HOURS Check for Loose Fasteners Clean / Inspect Grass Catcher * Check Tires Check Drive Wheels *** Clean Lawn Mower **** Clean under Drive Cover *** Check Drive Belt / Pulleys *** Check / Sharpen / Replace Blade Lubrication...
  • Page 11 LAWN MOWER Blade adapter Crankshaft keyway Always observe safety rules when per- form ing any main te nance. Lockwasher TIRES Blade • Keep tires free of gasoline, oil, or insect control chemi cals which can harm rubber. • Avoid stumps, stones, deep ruts, sharp objects and other hazards that may cause tire damage.
  • Page 12 Change the oil after every 25 hours of TO CHANGE AIR FILTER operation or at least once a year if the 1. Remove the air fi lter by turning clock wise lawn mower is not used for 25 hours in to the stop and pull away from collar.

  • Page 13: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: To avoid serious injury, Mowing Mowing before per form ing any service or ad just - position position ments: 1. Release control bar and stop engine. 2. Make sure the blade and all moving parts have completely stopped. 3.

  • Page 14: Storage

    STORAGE Immediately prepare your lawn mower for Operator MOWING presence POSITION storage at the end of the season or if the control bar unit will not be used for 30 days or more. LAWN MOWER When lawn mower is to be stored for a period of time, clean it thor oughly, remove FOLD all dirt, grease, leaves, etc.

  • Page 15: Troubleshooting

    ENGINE OIL • Replace your gasoline can if your can starts to rust. Rust and/or dirt in your Drain oil (with engine warm) and replace gasoline will cause problems. with clean engine oil. (See “ENGINE” in • If possible, store your unit indoors and the Maintenance section of this manual).
  • Page 16 TROUBLESHOOTING - See appropriate section in manual unless directed to a Sears Service Centre. PROBLEM CAUSE CORRECTION Loss of power 1. Rear of mower housing or 1. Raise cutting height. blade dragging in grass. 2. Cutting too much grass. 2. Raise cutting height. 3.
  • Page 17 SERVICE NOTES...

  • Page 18: Repair Parts

    REPAIR PARTS...
  • Page 20 TECUMSEH 4-CYCLE ENGINE MODEL NUMBER 143.056700...
  • Page 21 TECUMSEH 4-CYCLE ENGINE MODEL NUMBER 143.056700 KEY PART KEY PART DESCRIPTION DESCRIPTION 37465 Cylinder (Includes 151A 40017 Intake Valve Seal Key Numbers 2, 20 and 150) 37727 Engine Shroud 36783 * Valve Cover Gasket 26727 Dowel Pin 33734 Breather Element 36784 Valve Cover 36557...
  • Page 22 TECUMSEH 4-CYCLE ENGINE MODEL NUMBER 143.056700 KEY PART DESCRIPTION 640350 Carburetor (Includes Key Number 184 of Engine Parts List) 631615 Throttle Shaft & Lever Assembly 631767 Throttle Return Spring 631184 * Dust Seal Washer 631183 * Dust Seal (Throttle) 640070 Throttle Shutter 650506 * Shutter Screw...
  • Page 23 SERVICE NOTES...
  • Page 24 196912 02.02.05 BY Printed in U.S.A.
