Crown GTS-30 Installation & Operation Manual

Gas tilting skillets

Hide thumbs Also See for GTS-30:

Installation and operation manual (12 pages)

Table Of Contents

Quick Links

Installation & Operation Manual

Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury

or death. Read the installation, operating and maintenance instructions thoroughly before installing or

ANUAL 10093

EV 0 (04/21)

$21.00

Gas Tilting Skillets

GTS-30 & GTS-40

servicing this equipment.

CROWN FOOD SERVICE EQUIPMENT

70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9

Telephone: 919-762-1000

Model GTS-40

WARNING

A Middleby Company

www.crownsteamgroup.com

IMPORTANT FOR FUTURE REFERENCE

Please complete this information and retain this

manual for the life of the equipment:

Model #: ___________________________

Serial #: ___________________________

Date Purchased: _____________________

GAS TILTING SKILLETS

ANUAL

ECTION

Table of Contents

Need help?

Do you have a question about the GTS-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Crown GTS-30

Page 1 Serial #: ___________________________ Date Purchased: _____________________ Installation & Operation Manual Gas Tilting Skillets GTS-30 & GTS-40 Model GTS-40 WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment.
Page 2: Important Notes For Installation And Operation
This product is intended for commercial use only. NOT FOR HOUSEHOLD USE. NOTICE This manual should be retained for future reference. Copyright © 2021 by Crown. All rights reserved. Published in the United States of America. PAGE OF 12 INSTALLATION & OPERATION MANUAL 10093 REV 0 (04/21)
Page 3: Table Of Contents
Gas Tilting Skillets Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Installation Instructions ......................5 Operating Instructions ......................7 Cleaning ..........................8 Maintenance ......................... 9 Troubleshooting ........................
Page 4: Service Connections
29.3 Back [328 kg] (152 mm) * For use on non-combustible floors only. As continued product improvement is a policy of Crown, specifications are subject to changge without notice. PAGE OF 12 INSTALLATION & OPERATION MANUAL 10093 REV 0 (04/21)
Page 5: Installation Instructions
Gas Tilting Skillets NSTALLATION NSTALLATION NSTRUCTIONS NPACKING IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking the appliance, check for possible shipping damage. If the gas fired tilting skillet is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Prior to installation, verify that the type of gas supply (natural or propane) and electrical service agree with the specifications on the rating plate located on the left side panel as you face the front of the appliance.
Page 6 Gas Tilting Skillets NSTALLATION Gas Connections WARNING Do not connect the appliance to the electrical supply until after the gas connection has been made. CAUTION The pipe thread compound used when installing pipes must be a type that is resistant to the action of liquified petroleum or propane gases.
Page 7: Operating Instructions
Gas Tilting Skillets PERATION Operating Instructions CAUTION The appliance and its parts are hot. Use care when operating, cleaning and servicing the appliance. Before First Use Using a non-corrosive, grease-dissolving commercial cleaner, clean the protective metal oils from all surface parts and the interior of the tilting braising pan.
Page 8: Cleaning
Cleaning Gas Tilting Skillets Cleaning WARNING Disconnect the power supply to the appliance before cleaning or servicing. WARNING The appliance and its parts are hot. Use care when operating, cleaning and servicing the skillet. CAUTION Do not use cleaning agents that are corrosive. The gas fired tilting skillet should be cleaned after each use.
Page 9: Maintenance
Gas Tilting Skillets Maintenance Maintenance WARNING At least twice a year, have an authorized service person inspect and lubricate the tilt mechanism, replacing any worn or damaged parts. At least twice a year, have an authorized service person clean and adjust the unit for maximum performance. All units are adjusted at the factory.
Page 10: Troubleshooting
Gas Tilting Skillets ROUBLESHOOTING ROUBLESHOOTING Burners No Not Come On 1. Gas supply to unit is “OFF”. 2. Manual shut off valve is “OFF”. 3. Thermostat is not turned “ON”. 4. Pan not in lowest position. 5. Ignition control not functioning. 6.
Page 11 Gas Tilting Skillets Notes INSTALLATION & OPERATION MANUAL 10093 REV 0 (04/21) PAGE OF12...
Page 12 GTS-30 & GTS-40 Gas Tilting Skillets A product with the Crown name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
