4. AUX IN JACK
This jack is a convenient way to play music from an MP3 music player such
as an ipod through your car audio.
Simply connect the headphone output of the MP3 player to this input jack, and
press MODE button to select AUX as input source and begin playing music on
the MP3 player.
Please note:
AUX IN Mode can only be selected if it is enabled in the system Settings.
If you are having problems with AUX IN mode, please check the setting.
5&6. RADIO PRESETS 1-6
These buttons are used to store the presets for radio stations. To set a preset,
tune to the desired radio station. Then press and hold the preset to which you
wish to assign that station for more than one second and release. To replace it
with a different station, repeat the process and the new setting will override
the previous one.
7&8. REJECT AND ACCEPT A CALL
To pair the unit, turn on the Bluetooth mode of the mobile phone, then select the item
of finding the Bluetooth Device and enter it. After finishing the finding, it will show
the name of the Bluetooth Device if finding a Bluetooth Device. Select it and enter it,
then it will show a interface that ask you to input a password. Input the password
0000 and enter it.
Then it will tell you that pair OK and then connection OK, and the LCD of the car audio
system will show CONNECT and then show the name of the Bluetooth Device of the
mobile phone.
In BT mode, when receive a call, the LCD will show the receive phone number,
press the 8 button to accept the call and press the 7 button to reject the call.
Please note (in BT connect mode):
When your phone is connect to the head unit, the LCD will show BT-READY.
When dialling a call in connection status, the LCD will show CALL OUT.
9.BAND
Press briefly, repeatedly to cycle between the five radio bands:
FM1 > FM2 > FM3 > AM1 > AM2
10&11. TUNE/SEEK UP/DOWN BUTTONS
Press these buttons briefly to step up or down the radio dial in single step
increments. Press and hold for more than one-haft second and the tuner will
enter the SEEK mode. In this mode the tuner will stop at the next strong
station available.
12.DISPLAY
Press to display or adjust the clock. Press and hold this button until the time
flashing then use the volume knob to adjust the time.
PDF created with FinePrint pdfFactory trial version
Page 2
http://www.pdffactory.com

Installation

mounting case
support screw
head unit
Figure 1 Bending the support tabs
" "
Figure 3 Insert levers unit click occurs,
then use levels to pull out head unit.
dashboard attachment
surface
support strap
5mm nut
support screw
5x15mm
support screw
Figure 2 Forming the support bracket
