Operation

Using the Pressure Washer

IMPORTANT!
This pressure washer is equipped with a
micro-switch sensitive to water flow. This Total Stop System
(TSS) senses water flow in the pump. When the trigger is
released, water stops flowing through the pump. The TSS then
automatically turns the motor off to protect the pump from
overheating, thus saving energy and prolonging pump life.
1. Position the washer as CLOSE as possible to the water
supply. Press the trolley wheel locks down to secure the
unit (Fig. 8).
Fig. 8
Unlocked
2. The washer must be used on a secure and stable surface
in a horizontal position (Fig. 9).
Fig. 9
3. Make sure the unit is switched off before plugging the unit
into the power outlet.
4. Check that the electrical supply voltage and frequency
(Volt/Hz) correspond to those specified on the rating plate.
If the power supply is correct, you may now plug the
pressure washer into the power outlet (Fig. 10).
Fig. 10
NOTE: The GFCI may need to be reset when first plugged
into the electric outlet. Press the "Reset" button until
the power light indicator on the GFCI illuminates when
plugged in.
5. Turn the water supply tap on completely.
6. Make sure the safety lock is down and in its original
position (Fig. 11), then press the trigger for a few seconds
until water flow is steady. This will allow air to escape and
discharge any residual pressure in the hose.
Locked
Fig. 11
7. Turn the ON/OFF switch (pressure select dial) to the LOW (I)
or HIGH (II) position to start the pressure washer (Fig. 12).
9
Power light
indicator
GFCI
Safety lock
Reset
Slot
Trigger
