Know Your Electric Go Anywhere Pressure Washer
Read the owner's manual and safety rules carefully before operating the follow along pressure washer. Compare the illustration
below to the unit in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
3
4
5
6
7
8
1. Handle
2. Trigger gun
3. High-pressure hose connection
4. Soap tank cap
5. Soap tank
6. Water outlet
7. Trolley wheel lock (2)
8. Trolley wheel (2)

Technical Data

Rated Voltage ................................................... 120V ~ 60 Hz
Motor ...................................................................... 14.5-amp
Max Water Inlet Temperature .............................. 104ºF/40ºC
Max Water Inlet Pressure ......................................... 0.7 MPa
Max Flow with nozzle open ..................1.76 GPM (6.7 L/min)
at minimum pressure
Rated Flow .................................. Low 1.05 GPM (4.0 L/min)
under typical load .........................
1
2
9
9. High-pressure hose
10. Needle clean-out tool
11. Power cord with GFCI
12. Rear wheel (2)
13. Safety lock
14. Trigger
15. Trigger gun holder
16. Spray wand
17. Quick-connect collar
High 1.24 GPM (4.7 L/min)
19
20
21
22
23
24
25
26
11
10
18. ON/OFF switch (Pressure select dial)
19. Detergent dial
20. Soap Quick-Connect nozzle (black)
21. 40º Quick-Connect nozzle (gray)
22. 25º Quick-Connect nozzle (green)
23. 15º Quick-Connect nozzle (yellow)
24. Water inlet + Garden hose adapter (female coupler)
25. 0º Quick-Connect nozzle (red)
26. Nozzle storage board
Max Pressure at initial discharge ............................ 2030 PSI
per CSA internal pressure testing
Rated Pressure under typical load ..................... Low 870 PSI
..........................................................................High 1450 PSI
Detergent Tank Capacity ................................... 27 fl oz (0.8 l)
Hose Length ........................................................... 20 ft (6 m)
Power Cord Length ........................................... 35 ft (10.7 m)
Net Weight ..................................................... 19.4 lbs (8.8 kg)
6
18
15
14 16
12 13
17
