LED Lighting C-LITE C-BD-A-BLD Series Installation Instructions Manual

INSTALLATION INSTRUCTIONS
C-BD-A-BLD Series
CAUTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety
precautions should always be followed including the
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before
installation.
DANGER – Risque de choc – Couper l'alimentation
avant l'installation.
2. This luminaire must be installed in accordance with the
NEC or your local electrical code. If you are not familiar
with these codes and requirements, consult a qualified
electrician.
Ce produit doit être installé conformément à NEC ou votre
code électrique local. Si vous n'êtes pas familier avec ces
codes et ces exigences, veuillez contacter un électricien
qualifié.
3. Suitable for Wet Locations.
Adspte pour les Endroits Mouiles.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
NOTES
1. This carton contains fixture, anchor bolts and mounting
template. See reverse side for not-to-scale mounting
template.
FOUNDATION
1.
Foundation should be a minimum of 12 inches (305 mm) in diam-
eter, finished level and smooth, with a depth below grade of 24 (610
mm) inches. NOTE: in areas where frost is imminent, consult with a
civil engineer for a recommended foundation detail.
2. Provided are three 3/8" diameter x 11" (352 mm) long anchor bolts
and mounting template. Use template to set anchor bolts at proper
location (Note conduit entry allowance). Anchor bolts should project
2" (51 mm) above concrete.
following:
http://lighting.cree.com/warranty
Document: LPN00842X0001A0_A
Created By:
TMT
BOLLARD INSTALLATION
NOTE: Lens assembly does not need to be removed from
bollard pole during installation process.
1. To install bollard pole to anchor bolts, remove the (3) #8 x 1/2"
Phillips head screws at base of pole.
2. Begin lifting pole and lens assembly vertically off base. When wiring
quick disconnect is exposed, unlatch two halves of quick disconnect
and set pole/lens assembly aside.
3. Install base plate and inner frame assembly over anchor bolts and
secure with nuts, washers, and jam nuts provided.
NOTE: If leveling of the base is required, leveling nuts should be
used. Do NOT use shims.
4. Make electrical supply connections to terminal block on inner frame
assembly. See Electrical Connection section for proper wiring.
5. Reconnect two halves of quick disconnect from Step 2 and slide
pole/lens assembly over interior frame and base. Be careful not to
pinch any lead wires.
NOTE: Position pole so that #8 x 1/2" screws align with threaded
openings in base.
6. Tighten (3) #8 x 1/2" screws to secure pole/lens assembly to base.
Fixture is equipped with universal volt driver 120-277V
(ie. 120V, 208V, 240V or 277V)
ELECTRICAL CONNECTIONS
PHASE TO NEUTRAL WIRING 120/277V
1. Connect supply ground to fixture ground (green) lead.
2. Connect supply common to fixture neutral (white) lead.
3. Connect supply Vin to fixture hot (black) lead.
Tuck all wires carefully into wiring chamber ensuring that no
wires are pinched.
PHASE TO PHASE WIRING 208/240V
1. Connect supply ground to fixture ground (green) lead.
2. Connect supply L1 (Hot) to fixture neutral (white) lead.
3. Connect supply L2 (Hot) to fixture hot (black) lead.
Tuck all wires carefully into wiring chamber ensuring that no
wires are pinched.
FCC NOTICE
CAUTION: Changes or modifications not expressly approved could void
your authority to use this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CAN ICES-003 (A)/NMB-003 (A)
| 1-800-236-6800
Date 10-11-2020
