Furrion FSPK10MWT-BL User Manual

100W KICKSTAND SOLAR PANEL WITH
PWM BUNDLE KIT
MODEL: FSPK10MWT-BL
USER MANUAL
Content Includes:
●
100W Solar Panel
●
10A PWM Charge Controller
●
User Manual
●
Warranty Manual
* Product picture for reference only
!!ATTENTION!!
●
DO NOT use around open flammable sources.
●
DO NOT sit on this product.
●
DO NOT hang anything from this product.
●
DO NOT setup on elevated surfaces (roofs, tables).
●
DO NOT hang from elevated supports (trees, ladders).
●
DO NOT setup on un-even surfaces/terrains.
●
DO NOT setup or place wiring in any standing water.
●
DO NOT place wiring in travel paths (walking, vehicle).
●
DO NOT place panel in shaded areas (RV, trees, etc.).
●
ONLY use this product as intended, with Furrion products, any modification will
void the warranty.
SETUP AND OPERATION
Rotate base with sun
movement or leave panel
facing south
Swing support legs
open
NOTE: Ensure panel has stable footing.
CONNECTION
100W Kickstand
Solar Panel
100W Kickstand
Solar Panel
Charge Furrion ePod
100W Kickstand
Solar Panel
Charge Furrion ePod
Charge Furrion ePod TM
100W Kickstand
100W Kickstand
Solar Panel
Solar Panel
100W Kickstand
Solar Panel
Charge Furrion eRove
Charge Furrion eRove
Charge Furrion eRove
Overcast? – lay flat facing the sky
Charge 12V Battery
SETUP 10A PWM CHARGE CONTROLLER
10A PWM Charge Controller Status Indicators
LED indicators
Furrion ePod Charge Furrion ePod™ Power
TM
Power Station
Station
Furrion ePod TM
Power Station
Connect solar panel directly to ePower
Furrion ePod
TM station DC input (with battery installed
Power Station
– see ePod power station manual for
charging)
TM Power Station
TM Power Station
Power Station
Charge Furrion eRove™
Furrion eRove TM
Connect solar panel directly to eRove
Furrion eRove TM cooler solar input (with battery installed
Furrion eRove
TM
– see eRove manual for charging)
TM
TM
TM Charge 12V Battery
1. Connect solar panel directly to 10A
PWM charge controller (provided).
2. Connect controller to Furrion® solar
inlet.
10A PWM
Controller
3. Setup controller and charge.
10A PWM
Controller
10A PWM
Controller
Charge 12V Battery
Charge 12V Battery
Indications Status Functions
Solid on Solar panel has voltage
Solid off Solar panel has no voltage
Charging
Slow flashing Charging in process
Quick flashing System over voltage
Solid on Normal battery function
Solid off Battery is not connected
Battery
Slow flashing Battery is under voltage
Quick flashing Battery is over discharged
