Summary of Contents for Schiedel Isokern Celsius
- Page 1 Isokern Celsius Operating manual Schiedel Chimney Systems, Crowther Road, Crowther Industrial Estate Washington, Tyne & Wear NE38 0AQ – Tel. 0191 4161150 info.uk@schiedel.com Operation Manual Version 1.4 - 940003846 – 27-10-20...
-
Page 2: Table Of Contents
Celsius Operating Manual Contents Lighting and continuous firing in the Schiedel Celsius fireplace insert: ..............3 Wood types ...............................3 Fuel Overloading ..............................3 Refuelling on to a low fire bed ..........................3 Combustion air control lever ..........................3 Dampers left open ............................3 DEFRA Compliance for Smoke Controlled Areas ....................4 Lighting the fire ..............................6... -
Page 3: Lighting And Continuous Firing In The Schiedel Celsius Fireplace Insert
Celsius Operating Manual Lighting and continuous firing in the Schiedel Celsius fireplace insert: Wood types The fireplace insert is only approved for wood burning. It is recommended to use split birch or beech wood that has been seasoned for at least 1 year, preferably 2 years, outdoors in a suitable covered log store. -
Page 4: Defra Compliance For Smoke Controlled Areas
Celsius Operating Manual appliance must not be operated with air controls, appliance dampers or door left open except as directed in the instructions. When using the appliance in a smoke-controlled area, the appliance must be set up with the combustion air control lever in place using the DEFRA settings. DEFRA Compliance for Smoke Controlled Areas Unscrew the 4 screws on the cover plate Celsius Operating Manual 08/07/20... - Page 5 Celsius Operating Manual Remove the cover plate Lift the top plate. This will allow you to see the air control lever. Adjust the air control lever so that the holes shown as Defra holes in the images below are the ones which will be secured. Celsius Operating Manual 08/07/20 Page | 5...
-
Page 6: Lighting The Fire
Celsius Operating Manual Replace the steel plate on top and fix it with the 4 screws Lighting the fire When lighting the fire, we recommend that it be done using the "top down" method Start by placing 2-3 pieces of wood at the bottom of the combustion chamber. On top of these, lay approx. -
Page 7: Operation With Door Left Open
Celsius Operating Manual Feed the fire regularly with small amounts of logs. Don't overfill the chamber. It is important that the wood is dry and well-cut so that the surface area of the logs is large. This gives the optimum combustion performance. NOTE The MAX loading mark for logs is indicated by the row of holes in the back plate. -
Page 8: Maintenance Of The Fireplace Insert
Celsius Operating Manual Maintenance of the fireplace insert External cleaning This should only be done when the fireplace is cold. Daily maintenance is limited to a minimum. The easiest thing is to vacuum the fireplace outside with a small nozzle with soft brushes. -
Page 9: Soot
Celsius Operating Manual important to wait before adding new logs until there are only embers and no flames. Watch out for under pressure in your house, it can occur in both new and old houses because of the use of an extractor hood or dryer. Under pressure can also be created if the settings are incorrect on the ventilation system of a house. -
Page 10: Guarantee
In case of repair, we provide professional support. If an item is returned to Schiedel Chimney Systems Ltd. and it subsequently turns out that the damage is not covered by the guarantee, the accrued costs fall on the customer. -
Page 11: Ce Data Plate
Celsius Operating Manual Nominal Heat Output Recommended Chimney Draft Weight Smoke Departure Ø150 Net Efficiency Smoke gas mass flow Temp °C PM Emission mg/m CO Emissions 0,082 mg/m mg/ m Wood Capacity CE Data Plate Celsius Operating Manual 08/07/20 Page | 11... -
Page 12: Clean Air Act
Celsius Operating Manual Clean Air Act The Clean Air Act 1993 and Smoke Control Areas Under the Clean Air Act local authorities may declare the whole or part of the district of the authority to be a smoke control area. It is an offence to emit smoke from a chimney of a building, from a furnace or from any fixed boiler if located in a designated smoke control area. -
Page 13: Clearskies Level 5
Celsius Operating Manual clearSkies Level 5 Celsius has achieved the highest level in clearSkies certification clearSkies certified appliances meet the minimum performance level for Ecodesign regulations – the minimum legal requirement for an appliance manufactured in the UK from 1st January 2022. These criteria are the minimum energy efficiency of the appliance and the maximum levels of emissions permitted These new Ecodesign Regulations represent a significant tightening of these criteria over the... -
Page 14: Insert Dimensions
Celsius Operating Manual INSERT DIMENSIONS Celsius Operating Manual 08/07/20 Page | 14... - Page 15 Celsius Operating Manual Celsius Operating Manual 08/07/20 Page | 15...
- Page 16 Schiedel Chimney Systems Ltd. Unit 8 & 9, Block A, Holton Road Holton Heath Industrial Estate Poole, Dorset BH16 6LG Tel. +44 (0)1202 861650 sales.uk@schiedel.com | www.schiedel.com/uk...
