- Page 1 Small Fiber Laser User Guide 2000W Wuhan Raycus Fiber Laser Technologies Co., Ltd.
-
Page 2: Table Of Contents
2.6 Attentions..........................7 2.7 Specifications.........................7 3 Installation..........................11 3.1 Dimensions.......................... 11 3.1.1 Overall dimensions of RFL-C2000 small laser............11 3.2 Size and installation of output optical cable................ 12 3.2.1 RFL-C1000 ~ RFL-C2000 Output Optical Cable............12 3.3 Cooling system installation and requirements..............13 3.4 Installation rules........................14... - Page 3 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 4.7.3 External control mode (sequentially connected to 4.6)..........26 4.7.4 AD Mode........................27 4.7.5 controlling time-series chart..................28 4.7.6 Red Light Control......................29 4.8 Turning off the laser:......................29 5 Common Alarms and solutions....................
-
Page 4: Safety Information
User Guide of 2000W fiber laser 1 Safety Information Thank you for choosing Raycus fiber laser. This User Guide provides important safety, operation, maintenance and other information. Please read it carefully before using this product. To ensure safe operation and optimal... -
Page 5: Security Identifiers
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 1.3 Security Identifiers Raycus CW Fiber Lasers have different locations of safety identifiers depending on the model, as shown in Figure 1: Figure 1 Laser Security Identifiers Laser safety identifiers include: safety warning, laser fiber delivery cable connector warning, product certification, ID label, etc. -
Page 6: Optical Safety
4）There are no user serviceable parts, equipment or assemblies inside the product. All service and maintenance shall be performed by Raycus. In order to prevent electric shock, please do not break the seal or uncover the shield. Failure to comply with this instruction will void the warranty. -
Page 7: Product Description
Laser research 2.2 Model description Raycus continuous wave laser includes 100, 200L, 200, 300L, 300, 500, 750, 1000,1500 and other models, which respectively represent 100W, 170W, 200W, 250W, 300W, 500W, 750W, 1000W and 1500W lasers. The definitions of the... -
Page 8: Package Accessories
Please refer to package accessories are in the packing box. 2.4 Unpacking and Inspection Raycus fiber laser is delivered with the specially designed package to offer the fiber laser maximal safety. Nevertheless, in order to prevent the occurrence of unpredictable circumstances during the transportation, please inspect all packaging once receiving the delivery. - Page 9 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Power 380±15% V AC Voltage(V) 50/60Hz Power Capacity （kW） Installation Flat and no vibration Environment Ambient Temperature 10～40 (℃) Relative ＜70 Humidity （％） Warning: 1）Make sure the product is properly grounded before use.
-
Page 10: Attentions
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 10.5 18.5 21.5 19.5 28.5 27.5 33.5 Laser operating temperature range 2.6 Attentions 1) Make sure that the correct voltage (according to Table 3) is used before connecting AC current. - Page 11 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Table 5 Product Specifications Model C2000 C2000H Test Conditions Optical Characteristics Output Power(W) 2000 Operation Mode CW/Modulated Polarization State Random Power range(%) 10~100 Central Wavelength 1080±5 Nominal Output Power (nm) Nominal Output Power;...
- Page 12 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Half Angle Divergence Nominal Output Power， 4δStandard ≤0.06 （rad） Beam quality (M²) Core Fiber(μm) 50（100、200 are optional） Delivery Cable (m) Customizable length () () Electrical Characteristics Power Supply 380±...
- Page 13 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Storage -10~60 Temperature(℃) Cooling Method Water Cooling Raycus User Guide | Product Description...
-
Page 14: Installation
User Guide of 2000W fiber laser 3 Installation 3.1 Dimensions 3.1.1 Overall dimensions of RFL-C2000 small laser Figure 2 shows the dimensions of the RFL-C2000 laser. Figure 2 (a) Front view (Unit: mm) Figure 2 (b) Rear view (unit: mm) Raycus User Guide | Installation... -
Page 15: Size And Installation Of Output Optical Cable
Raycus continuous wave fiber laser uses different laser output cables according to different laser models. 3.2.1 RFL-C1000 ~ RFL-C2000 Output Optical Cable The output cables of Raycus RFL-C1000 ~ RFL-C2000 small lasers are self-made IQB output cables. The specific appearance dimensions are shown in Figure 4 below:... -
Page 16: Cooling System Installation And Requirements
If the lens is dirty, it must be cleaned. It is forbidden to disassemble the output lens by anyone other than Raycus, otherwise the warranty will be invalid. 3.3 Cooling system installation and requirements Table 6 Cooling System Requirements... -
Page 17: Installation Rules
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser If ambient temperature is between -10℃ and 0℃, we recommend to use 30% alcohol(volume ratio), and replace it every 2 months. If ambient temperature is below -10 ℃ , the chiller with both heating and cooling functions must be used, and keep it in full-time operation. - Page 18 5) Please check the laser fiber delivery cable connector and do the necessary cleaning before installing it in the device. If you find that there is dust or foreign objects that cannot be cleaned, please contact Raycus in time, and do not continue installation and operation for the time being.
-
Page 19: Using The Product
Web：http://www.raycuslaser.com/index.php/index-show-tid-53.html 4.1 Front panel Figure 5 shows the front panel style of RFL-C1000 ~ RFL-C2000 welding laser (taking RFL-C1000 as an example, the front panel styles of other products are the same): Figure 5 RFL-C1000 laser front panel 4.2 Rear Panel... -
Page 20: Power Connection
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 2. Laser：Laser output indicator lamp 3. Power ： The laser power indicator lamp is on, indicating that the laser is powered on. 4. Water pipe joint: Pagoda joint, insert the quick-plug water pipe with an outer diameter of 16 into the pagoda head and fasten it with a clamp to connect the laser to the circulating cooling water. -
Page 21: Interface Definition
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Table 7 Power connection requirements Model RFL-C2000 380±15% V AC Power supply 50/60Hz Power cord Power cord Four strands, marked L1, L2,L3 and PE respectively L1->Phase line (brown) L2 ->... -
Page 22: Rs-232 Serial Port
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser supply Reserve Short emergency circuit stop Analog External analog Analog 0-10V <10mA input quantity setting (100%) （0%） Laser Analog Optical power signal 3.3V <10mA Power output output... - Page 23 A three-core (RxD, TxD, GND) crossing line is used. For specific commands and descriptions, please refer to the software manual of the host computer or ask a Raycus technician for a communication protocol. The specific parameter settings of the RS-232 control interface are as follows:...
-
Page 24: Ethernet Tcp / Ip Interface And Connection Steps
IP address of the laser; if you do not use the upper computer of Raycus, please directly enter the fourth step;... - Page 25 Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser IP address must be on the same network segment as the laser IP address, and assign a subnet mask address. The default is 255.255.255.0. Click the "OK" button to confirm the settings and exit.
-
Page 26: Installation Instruction
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Figure 10 Ethernet connection steps 4.5 Installation Instruction 1) Take out the laser carefully, move it to the installation position, remove the handle, and use the handle to install the hole position to fix it with screws. -
Page 27: Start Operation Sequence
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser output optical cable, remove the protective cap, and check whether the output lens is clean again, and then install the fiber delivery cable connector; 4) Connect the laser cooling water pipe;... -
Page 28: Control Mode Selection
Figure 11 Wiring diagram in RS-232 mode Note: The above modes need to be modified by raycus upper computer to turn off the red light external control, external light output enable and external AD, and only the modulation mode is reserved. -
Page 29: Stand-Alone Mode (Internal Control Mode) (Connect 4.6 In Sequence)
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 4.7.2 Stand-alone mode (internal control mode) (connect 4.6 in sequence) 1) Turn on the rocker switch, and the panel "power" indicator light is on 2) Wait for 20s, internal main control board circuit initialization is completed. -
Page 30: Ad Mode
(0v-0% power, 10v-100% power). If the upper computer selects external AD mode off, the laser power is set by serial port or Ethernet, and the Raycus hand-heldwelding laser will enter external ad mode by default when powered on. Raycus User Guide |... -
Page 31: Controlling Time-Series Chart
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser 4.7.5 Controlling time-series chart Figure 13 Standalone mode—Continuous sequence diagram Figure 14 Standalone mode – Pluse sequence diagram Raycus User Guide | Using the Product... -
Page 32: Red Light Control
Wuhan Raycus Fiber Laser Technologies Co., Ltd User Guide of 2000W fiber laser Figure 15 Modulation—sequence diagram Figure 16 Gate mode –sequence diagram 4.7.6 Red Light Control Turn on the rocker switch, the green "POWER" indicator light is on. Waiting for 20s, the laser enters the red-light external control mode, and a high level of 5-24V is given before the 17-20 feet. -
Page 33: Common Alarms And Solutions
5.1 Alarm display Connect the computer and open the PC software (download the PC software and its instruction manual, please log on the Raycus official website), after the laser and client software establish normal communication. All laser alarm states can be displayed on the client software interface, as shown in Figure 17. The laser will give an alarm in the case of abnormal internal temperature, abnormal output power, abnormal power supply, abnormal condensation, etc. - Page 34 Instruction: System Timer Internal clock abnormal Alarm Solutions: When this alarm occurs, please contact Raycus directly Instruction: This alarm occurs when the light exit button on the front panel of the laser has been pressed before powering on. Solutions: Laser On Button...
- Page 35 Please wait until the water temperature of the water rises above 10°C and then restart the divice. If the alarm continues, please contact Raycus. Instruction: The laser detects that the current temperature of the water-cooled plate is lower than the current dew point temperature of the laser.
-
Page 36: Warranty, Return And Maintenance
Raycus. The customer has the responsibility to understand and follow this instruction to use the device. Any damage caused by fault operating is not warranted. -
Page 37: Service And Repair
Raycus. When you receive Raycus products, please check whether the products are intact in time. If there is any abnormality, please contact the carrier or Raycus in time. Raycus will continue to develop new products. The product information listed in the manual is subject to change without further notice.
