Monogram ZBD68XXK Owner's Manual

A Quick Start to Your
Monogram Dishwasher
Read the Owner's Manual for complete Operating Instructions.
Indicator
window
Pub. No. 49-5968-1
Part No. 165D4700P292
06-04 JR

Before You Start

 Water temperature should be at least 120°F (49°C) for efficient cleaning and
no more than 150°F (66°C) to prevent damage to your dishes.

Loading Your Dishes

 Do not obstruct spray arms.
 Do not block detergent cup with tall objects. The detergent cup must
dispense detergent freely so it can circulate during the wash cycle.
 Load the silverware basket evenly. Mix knives, spoons and forks so they won't
nest together.
 Use rinse agent to prevent spotting (see page 9).
Dispenser cap
 Add rinse agent until the indicator window shows full.

Starting the Dishwasher

 Select the desired cycle. Press the up or down arrow until the light next to
the desired cycle is on.
 Select any enhancements, if desired, then press START/RESET.
 Close and latch the door. The cycle will begin.
 The CLEAN indicator light will glow when the cycle is completed.
 The dishwasher will remember which cycle and enhancements were used last. If
you don't want to change the settings, press START/RESET to begin a new cycle.
 If the door is closed, the indicator lights will turn off if the START/RESET
pad is not selected within 2 minutes. To activate, open and close the door or
press any pad.

Interrupting the Cycle

 Open the door slowly, just enough to stop the wash cycle. Close and latch the
door; the cycle will automatically resume.

Reset/Canceling the Cycle

 Open the door slowly to prevent splash-out. Touch the START/RESET pad
to cancel the cycle.
 If the START/RESET light is flashing, close the door until the water pumps
out (this can take approximately 70 seconds). When the light stops flashing,
the diswasher can be reprogrammed and restarted.

Child Lock-out

 To lock the controls and prevent unwanted operation, press and hold
HEATED DRY for 3 seconds. To unlock, press and hold HEATED DRY
for 3 seconds.

Troubleshooting

 If you find any damage to the dishwasher, contact the installer immediately.
G E M o n o g r a m D i s h w a s h e r
(See pages 11 to 14 in the Owner's Manual)
(See pages 16 to 19 in the Owner's Manual)
Z B D 6 8 X X K
Z B D 0 7 X X K
