- Page 1 BG-AMP2X50 2x50W Class-D Amplifier w/ 5 Inputs USER MANUAL...
- Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
Table of Content Introduction ........................4 Features ........................4 Panel Descriptions ...................... 5 Front Panel ......................5 Back Panel ......................6 Remote Control Description ..................7 Application Diagram ....................8 Specifications ....................... 9 Package Contents ..................... 10 RS-232 Pin Assignment ................... 10 RS232 and Telnet Commands ................ -
Page 4: Introduction
Introduction The BG-AMP2X50 is a compact class-D amplifier with 5 inputs, it features switchable stereo or bridge output, and complete EQ adjustment and intuitive working status display. It integrates easily in various analog to digital applications such as when used in collaboration environments, lecture halls, conference rooms, classrooms, healthcare facilities and control centers. -
Page 5: Panel Descriptions
(ON/OFF). Rotate the “Volume Rotary Knob” can adjust the volume directly. ② IR Receiver Window - Receive IR signal from the remote control of BG-AMP2X50. ③ Power Button – Long press (2 seconds) it to enter standby mode, and short press it to wake up. -
Page 6: Back Panel
Back Panel ① TCP/IP Port – IP Control / LAN Serving ② RS232 Port – For control the BG-AMP2X50 thru computer or central controller. ③ Optical Port – Optical digital audio (SPDIF) input. ④ Coaxial Port – Coaxial digital audio (SPDIF) input. -
Page 7: Remote Control Description
Remote Control Description Power On the unit Power Off the unit Mute, Unmute, Select EQ modes Decrease, Increase volume Mic Embed control Select the audio input sources Bridge mode control Decrease/increase the audio delay value (Optional) Note: A small plastic tab extends out from the remote control battery compartment. This must be removed before using the remote control. -
Page 8: Application Diagram
Application Diagram... -
Page 9: Specifications
Specifications Technical Power output 2x50W@8ohms, 1x100W@4ohms 85dB THD+ N 1%@1KHz 50W@8ohms, 1%@1KHz 100W@4ohms Frequency response 100Hz to 20KHz (±3 dB) Impedance 2-8 ohms >10KΩ Input Impedance Max Input Voltage swing 5.6V Input Channel Separation 90dB Efficiency Human body model — ±15kV (air-gap discharge) & ±8kV (contact ESD Protection discharge) Inputs... -
Page 10: Package Contents
Package Contents 1x BG-AMP2X50 1x 30V/5A DC Power Supply 1x Power Cord 1x Remote Control 1x IR Receiver 2x Rack-mount Ears (19” Rack-Mountable RS-232 Pin Assignment BG-AMP2X50 (DCE) Remote Control Console (DTE) Assignment Assignment Baud Rate: 57600 bps Data Bit: 8-bit... -
Page 11: Rs232 And Telnet Commands
RS232 and Telnet Commands Command Action Print Help Information HELP Print Help Information STATUS Print System Status And Port Status Power On, System Run On Normal State POFF Power Off, System Run On Power Save State LCD ON/OFF Set LCD Always On Or Auto Turn Off In Power On State Reset System To Default Setting (Should Type "Yes"... -
Page 12: Maintenance
Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit. Warranty Policy BZBGEAR products are warranted against defects in material and workmanship for one year from the date of shipment. During the warranty period, BZBGEAR will, at its option, repair or replace products that prove to be defective. -
Page 13: Exclusive Remedies
The warranty does not cover replacement or repair necessitated by loss or damage from any cause beyond the control of BZBGEAR, such as lightning or other natural and weather-related events or wartime environments. The warranty does not cover any labor involved in the removal and or reinstallation of warranted equipment or parts on site, or any labor required to diagnose the necessity for repair or replacement. -
Page 14: Once You Have Obtained An Rma Number
An RMA number must first be issued by sales. This RMA number will need to be referenced on the outside of the return shipment. Upon receipt of the defective product, BZBGEAR will, at its discretion, either repair or replace the product and ship it out in the most expeditious manner possible. Subject to availability, the replacement product will be shipped on the business day following receipt of the defective product. -
Page 15: Warranty Information (Second Year Assurance)
Warranty Information (Second Year Assurance) BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple, just follow the steps below: 1. -
Page 16: Mission Statement
Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.
