- Page 1 BG-DA-12GS1X2 1x2 12G/6G/3G/HD/SD-SDI Distribution Amplifier with Reclocking User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ......................... 1 FEATURES ..........................1 PACKAGE CONTENTS ......................1 SPECIFICATIONS ........................2 PANEL DESCRIPTIONS ......................3 HARDWARE INSTALLATION ....................3 CONNECTION DIAGRAM ......................4 SIGNAL MEASUREMENT ......................5 WARRANTY ..........................6 MISSION STATEMENT ......................7... -
Page 3: Introduction
INTRODUCTION The BG-DA-12GS1X2 1x2 12G/6G/3G/HD/SD-SDI Distribution Amplifier with Reclocking receives one SDI input, duplicates it, and re-transmits two SDI outputs for real time multi-viewing. It reliably splits an SDI, HD-SDI, 3G-SDI, 6G-SDI, or 12G-SDI video source to two SDI compliant displays at the same time. -
Page 4: Specifications
SPECIFICATIONS Model Name BG-DA-12GS1X2 Technical SDI standard SD/HD/3G/6G/12G-SDI Multi-Rate Support Auto detection of SD, HD, 3G, 6G or 12G Signals SMPTE 424M, SMPTE 292M, SMPTE 344M, SMPTE 259M, DVB-ASI, ST- SDI Compliance 2081(6G), ST2082(12G) SDI Data rates 1.485 / 2.97 / 5.94 / 11.88 Gbps Video bandwidth [11.88Gpbs &... -
Page 5: Panel Descriptions
10. SD Signal LED indicator 11. 12G/6G/3G/HD/SD-SDI output HARDWARE INSTALLATION 1. Connect a camera or other device equipped with 12G/6G/3G/HD/SD-SDI outputs to BG-DA-12GS1X2 12G/6G/3G/HD/SD-SDI input. 2. Connect device equipped with 12G/6G/3G/HD/SD-SDI inputs (e.g. monitors or video processors) to BG-DA-12GS1X2 12G/6G/3G/HD/SD-SDI outputs. -
Page 6: Connection Diagram
CONNECTION DIAGRAM... -
Page 7: Signal Measurement
SIGNAL MEASUREMENT... -
Page 8: Warranty
WARRANTY BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*. Taking advantage of this program is simple, just follow the steps below: 1. -
Page 9: Mission Statement
MISSION STATEMENT BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank.
