- Page 1 Gewässer Umwelt Schutz GmbH AUW oil protector Assembly instructions...
- Page 2 Introduction These assembly instructions must be read carefully before commissioning and using the AUW oil protector! These assembly instructions are considered part of the AUW oil protector and must always be kept in the immediate vicinity of the installation site, or with the pro- tector itself.
- Page 3 AUW oil protector - assembly instructions Product overview Standard sizes L x W x H mm Oil quantity Ltr. AUW 1 320 x 900 x 35 1,19 AUW 2 400 x 950 x 35 1,52 AUW 3 500 x 1.150 x 35 2,30 AUW 4 850 x 1.140 x 35...
- Page 4 • The condensate drip tray must be earthed. • Modifications to the protectors or their components supplied by GUS Gewässer-Umwelt-Schutz GmbH may cause malfunctions and are not per- mitted. The AUW oil protectors and their components must not be ope- rated in areas where there is an increased risk of damage.
- Page 5 AUW oil protector - assembly instructions Recycling Removal of packaging All products are carefully packed for trans- port. Make a valuable contribution to was- te prevention and conservation of raw ma- terials and dispose of packaging materials only at designated collection points. Warranty Warranty conditions are listed in “Gene- ral Terms and Conditions”.
- Page 6 AUW oil protector scope of delivery Mounting feet AUW oil protector 2 pieces per AUW oil protector as depicted Note: Locking screws 2 pieces per AUW oil protector Check if your delivery is complete. Assembly The separator works according to the The dimensions allow the installation of same principle as the CUW Oil Protector.
- Page 7 AUW oil protector - assembly instructions Warning Make sure that other metals do not come into contact with the AUW Oil Protector, or obtain information about possible bimetal- lic corrosion. Maintenance Because leaves and other particles can impair the function of the AUW Oil Protec- tor, make sure it is checked and cleaned regularly.
- Page 8 Gewässer Umwelt Schutz GmbH Bentheimter Str. 300 48531 Nordhorn T: +49 (0) 5921 71347-0 info@oelprotektor.de Ölprotektor.de...
